Appendix

Message List

The following messages and indications may appear for this camera. Perform the following as necessary.

Lamp display

Lamp Meaning and solution

POWER and NETWORK lights

flash simultaneously.

A hardware failure (internal temperature abnormal or FAN motor faulty) is detected.

Check if the FAN motor is running.
