145
STR-DA5300ES
Pin No. Pin Name I/O Description
P8
DAI_P3 - Not used
P9
SF2_DSP2_MAS O Master/slave selection signal output terminal
P10 DPSOA O
PCM audio signal (front L/R) output to the lip sync adjust
P11 DPSOB O
PCM audio signal (surround L/R) output to the lip sync adjust
P12 DPSOC O
PCM audio signal (center, sub woofer) output to the lip sync adjust
P13 DPSOD O
PCM audio signal (surround back L/R) output to the lip sync adjust
P14 DPSIA I
PCM audio signal (digital input) input from the DSP1
