148
STR-DA5300ES
D-VIDEO BOARD IC3503, 3504 SII9185CTU (HDMI INPUT SELECT)
Pin No.
Pin Name I/O Description
1
TX2+ O TMDS data (positive) output to the HDMI receiver
2
TX2- O TMDS data (negative) output to the HDMI receiver
3
AGND - Ground terminal
4
TX1+ O TMDS data (positive) output to the HDMI receiver
5
TX1- O TMDS data (negative) output to the HDMI receiver
6
AVCC18 - Power supply terminal (+1.8V)
7
TX0+ O TMDS data (positive) output to the HDMI receiver
8
TX0- O TMDS data (negative) output to the HDMI receiver
9
AGND - Ground terminal
10
TXC+ O TMDS clock (positive) output to the HDMI receiver
11
TXC- O TMDS clock (negative) output to the HDMI receiver
12
EXTSWING - Not used
13
RESET# I Reset signal input from the video system controller "L": reset
14
LSDA/EPSEL[0] I/O
I2C two-way data bus with the video system controller, EEPROM, HDMI receiver, HDMI
transceiver and D/A converter
15
LSCL/EPSEL[1] I I2C clock signal input from the video system controller
16
HPD0 O Hot plug detection signal output to the HDMI ASSIGNABLE (INPUT ONLY) IN jack
17
AVCC18 - Power supply terminal (+1.8V)
18
R0XC- I TMDS clock signal (negative) input from the HDMI ASSIGNABLE (INPUT ONLY) IN jack
19
R0XC+ I TMDS clock signal (positive) input from the HDMI ASSIGNABLE (INPUT ONLY) IN jack
20
AGND - Ground terminal
21
R0X0- I TMDS data (negative) input from the HDMI ASSIGNABLE (INPUT ONLY) IN jack
22
R0X0+ I TMDS data (positive) input from the HDMI ASSIGNABLE (INPUT ONLY) IN jack
23
AVCC33 - Power supply terminal (+3.3V)
24
R0X1- I TMDS data (negative) input from the HDMI ASSIGNABLE (INPUT ONLY) IN jack
25
R0X1+ I TMDS data (positive) input from the HDMI ASSIGNABLE (INPUT ONLY) IN jack
26
AGND - Ground terminal
27
R0X2- I TMDS data (negative) input from the HDMI ASSIGNABLE (INPUT ONLY) IN jack
28
R0X2+ I TMDS data (positive) input from the HDMI ASSIGNABLE (INPUT ONLY) IN jack
29
AVCC18 - Power supply terminal (+1.8V)
30
DSDA0 I/O I2C two-way data bus with the HDMI ASSIGNABLE (INPUT ONLY) IN jack
31
DSCL0 I I2C clock signal input from the HDMI ASSIGNABLE (INPUT ONLY) IN jack
32
RPWR0 I Power supply voltage (+5V) input from the HDMI ASSIGNABLE (INPUT ONLY) IN jack
33
DVCC18 - Power supply terminal (+1.8V)
34
DGND - Ground terminal
35
I2CSEL/INT - Not used
36
HPD1 O Hot plug detection signal output to the HDMI ASSIGNABLE (INPUT ONLY) IN jack
37
AVCC18 - Power supply terminal (+1.8V)
38
R1XC- I TMDS clock signal (negative) input from the HDMI ASSIGNABLE (INPUT ONLY) IN jack
39
R1XC+ I TMDS clock signal (positive) input from the HDMI ASSIGNABLE (INPUT ONLY) IN jack
40
AGND - Ground terminal
41
R1X0- I TMDS data (negative) input from the HDMI ASSIGNABLE (INPUT ONLY) IN jack
42
R1X0+ I TMDS data (positive) input from the HDMI ASSIGNABLE (INPUT ONLY) IN jack
43
AVCC33 - Power supply terminal (+3.3V)
44
R1X1- I TMDS data (negative) input from the HDMI ASSIGNABLE (INPUT ONLY) IN jack
45
R1X1+ I TMDS data (positive) input from the HDMI ASSIGNABLE (INPUT ONLY) IN jack
