Sony STR-DA5300ES - Page 149

149
STR-DA5300ES
Pin No.
Pin Name I/O Description
46
AGND - Ground terminal
47
R1X2- I TMDS data (negative) input from the HDMI ASSIGNABLE (INPUT ONLY) IN jack
48
R1X2+ I TMDS data (positive) input from the HDMI ASSIGNABLE (INPUT ONLY) IN jack
49
AVCC18 - Power supply terminal (+1.8V)
50
DSDA1 I/O I2C two-way data bus with the HDMI ASSIGNABLE (INPUT ONLY) IN jack
51
DSCL1 I I2C clock signal input from the HDMI ASSIGNABLE (INPUT ONLY) IN jack
52
RPWR1 I Power supply voltage (+5V) input from the HDMI ASSIGNABLE (INPUT ONLY) IN jack
53, 54
CEC_D, CEC_A - Not used
55
AVCC33 - Power supply terminal (+3.3V)
56
HPD2 O Hot plug detection signal output to the HDMI ASSIGNABLE (INPUT ONLY) IN jack
57
AVCC18 - Power supply terminal (+1.8V)
58
R2XC- I TMDS clock signal (negative) input from the HDMI ASSIGNABLE (INPUT ONLY) IN jack
59
R2XC+ I TMDS clock signal (positive) input from the HDMI ASSIGNABLE (INPUT ONLY) IN jack
60
AGND - Ground terminal
61
R2X0- I TMDS data (negative) input from the HDMI ASSIGNABLE (INPUT ONLY) IN jack
62
R2X0+ I TMDS data (positive) input from the HDMI ASSIGNABLE (INPUT ONLY) IN jack
63
AVCC33 - Power supply terminal (+3.3V)
64
R2X1- I TMDS data (negative) input from the HDMI ASSIGNABLE (INPUT ONLY) IN jack
65
R2X1+ I TMDS data (positive) input from the HDMI ASSIGNABLE (INPUT ONLY) IN jack
66
AGND - Ground terminal
67
R2X2- I TMDS data (negative) input from the HDMI ASSIGNABLE (INPUT ONLY) IN jack
68
R2X2+ I TMDS data (positive) input from the HDMI ASSIGNABLE (INPUT ONLY) IN jack
69
AVCC18 - Power supply terminal (+1.8V)
70
DSDA2 I/O I2C two-way data bus with the HDMI ASSIGNABLE (INPUT ONLY) IN jack
71
DSCL2 I I2C clock signal input from the HDMI ASSIGNABLE (INPUT ONLY) IN jack
72
RPWR2 I Power supply voltage (+5V) input from the HDMI ASSIGNABLE (INPUT ONLY) IN jack
73
DVCC18 - Power supply terminal (+1.8V)
74
DGND - Ground terminal
75
RSVDL - Not used
76
HPDIN I Hot plug detection signal input from the video system controller
77
TSDA I/O I2C two-way data bus with the EEPROM and HDMI receiver
78
TSCL O I2C clock signal output to the EEPROM and HDMI receiver
79
TPWR/I2CADDR
O Power supply voltage (+5V) output to the HDMI receiver
80
AGND - Ground terminal
