D-VIDEO BOARD IC3511 SII9135CTU (HDMI RECEIVER)
Pin No.
Pin Name I/O Description
1 to 3
Q10 to Q8 O Serial data output to the HDMI transceiver and video processor
4
IOGND - Ground terminal
5
ODCK O Output data clock signal output to the HDMI transceiver, video processor and D/A converter
6
IOVCC33 - Power supply terminal (+3.3V)
7 to 10
Q7 to Q4 O Serial data output to the HDMI transceiver and video processor
11
CGND - Ground terminal
12
CVCC18 - Power supply terminal (+1.8V)
13 to 16
Q3 to Q0 O Serial data output to the HDMI transceiver
17
IOGND - Ground terminal
18
IOVCC33 - Power supply terminal (+3.3V)
19
DE O Data enable signal output to the HDMI transceiver, video processor and D/A converter
20
HSYNC O Horizontal sync signal output to the HDMI transceiver, video processor and D/A converter
21
VSYNC O Vertical sync signal output to the HDMI transceiver, video processor and D/A converter
22
EVNODD - Not used
23
CGND - Ground terminal
24, 25
CVCC18 - Power supply terminal (+1.8V)
26
CSDA I/O
I2C two-way data bus with the EEPROM, HDMI input select, HDMI transceiver, video system
controller and D/A converter
27
CSCL I I2C clock signal input from the video system controller
28
DSDA1 I/O I2C two-way data bus with the HDMI input select and EEPROM
29
DSCL1 I I2C clock signal input from the HDMI input select
30
R1PWR5V I Power supply voltage (+5V) input from the HDMI input select
31
IOGND - Ground terminal
32
IOVCC33 - Power supply terminal (+3.3V)
33
DSDA0 I/O I2C two-way data bus with the HDMI input select and EEPROM
34
DSCL0 I I2C clock signal input from the HDMI input select
35
R0PWR5V I Power supply voltage (+5V) input from the HDMI input select
36
AGND - Ground terminal
37
AVCC18 - Power supply terminal (+1.8V)
38
AVCC33 - Power supply terminal (+3.3V)
39
R0XC- I TMDS clock (negative) signal input from the HDMI input select
40
R0XC+ I TMDS clock (positive) signal input from the HDMI input select
41
AGND - Ground terminal
42
AVCC33 - Power supply terminal (+3.3V)
43
R0X0- I TMDS data (negative) input from the HDMI input select
44
R0X0+ I TMDS data (positive) input from the HDMI input select
45
AGND - Ground terminal
46
AVCC33 - Power supply terminal (+3.3V)
47
R0X1- I TMDS data (negative) input from the HDMI input select
48
R0X1+ I TMDS data (positive) input from the HDMI input select
49
AGND - Ground terminal
50
AVCC33 - Power supply terminal (+3.3V)
51
R0X2- I TMDS data (negative) input from the HDMI input select
52
R0X2+ I TMDS data (positive) input from the HDMI input select
53
AGND - Ground terminal
54
AVCC18 - Power supply terminal (+1.8V)
