STR-DA5300ES
Pin No.
Pin Name I/O Description
55
RSVDNC - Not used
56
AVCC33 - Power supply terminal (+3.3V)
57
R1XC- I TMDS clock (negative) signal input from the HDMI input select
58
R1XC+ I TMDS clock (positive) signal input from the HDMI input select
59
AGND - Ground terminal
60
AVCC33 - Power supply terminal (+3.3V)
61
R1X0- I TMDS data (negative) input from the HDMI input select
62
R1X0+ I TMDS data (positive) input from the HDMI input select
63
AGND - Ground terminal
64
AVCC33 - Power supply terminal (+3.3V)
65
R1X1- I TMDS data (negative) input from the HDMI input select
66
R1X1+ I TMDS data (positive) input from the HDMI input select
67
AGND - Ground terminal
68
AVCC33 - Power supply terminal (+3.3V)
69
R1X2- I TMDS data (negative) input from the HDMI input select
70
R1X2+ I TMDS data (positive) input from the HDMI input select
71
AGND - Ground terminal
72
AVCC18 - Power supply terminal (+1.8V)
73
IOGND - Ground terminal
74
IOVCC33 - Power supply terminal (+3.3V)
75
MUTEOUT O Audio muting control signal output terminal
76, 77
RSVDNC - Not used
78
SPDIF O S/PDIF signal output to the digital audio interface receiver and HDMI transceiver
79
CGND - Ground terminal
80
CVCC18 - Power supply terminal (+1.8V)
81
SD0 O PCM audio signal output to the DSP1, DSP2 and HDMI transceiver
82 to 84
SD1 to SD3 O PCM audio signal output to the DSP1 and HDMI transceiver
85
WS O L/R sampling clock signal output to the DSP1, DSP2 and HDMI transceiver
86
SCK O Bit clock signal output to the DSP1, DSP2 and HDMI transceiver
87
IOGND - Ground terminal
88
IOVCC33 - Power supply terminal (+3.3V)
89
MCLK O Master clock signal output to the DSP1, DSP2 and HDMI transceiver
90
CGND - Ground terminal
91
CVCC18 - Power supply terminal (+1.8V)
92
DVCC18 - Power supply terminal (+1.8V)
93
DGND2 - Ground terminal
94
XTALOUT O System clock output terminal (28.322 MHz)
95
XTALIN I System clock input terminal (28.322 MHz)
96
XTALVCC - Power supply terminal (+3.3V)
97
REGVCC - Power supply terminal (+3.3V)
98
RSVDNC - Not used
99
RSVDL - Not used
100
RESET# I Reset signal input from the video system controller "L": reset
101
SCDT - Not used
102
INT O Interrupt signal output to the video system controller
103
IOGND - Ground terminal
104
IOVCC33 - Power supply terminal (+3.3V)
