152
STR-DA5300ES
Pin No.
Pin Name I/O Description
105
CI2CA - Not used
106
CGND - Ground terminal
107
CVCC18 - Power supply terminal (+1.8V)
108 to 111
Q35 to Q32 O Serial data output to the HDMI transceiver, video processor and D/A converter
112
IOGND - Ground terminal
113
IOVCC33 - Power supply terminal (+3.3V)
114 to 117
Q31 to Q28 O Serial data output to the HDMI transceiver, video processor and D/A converter
118
CGND - Ground terminal
119
CVCC18 - Power supply terminal (+1.8V)
120 to 123
Q27 to Q24 O Serial data output to the HDMI transceiver
124
IOGND - Ground terminal
125
IOVCC33 - Power supply terminal (+3.3V)
126 to 129
Q23 to Q20 O Serial data output to the HDMI transceiver, video processor and D/A converter
130
CGND - Ground terminal
131
CVCC - Power supply terminal (+1.8V)
132 to 135
Q19 to Q16 O Serial data output to the HDMI transceiver, video processor and D/A converter
136
IOGND - Ground terminal
137
IOVCC33 - Power supply terminal (+3.3V)
138 to 141
Q15 to Q12 O Serial data output to the HDMI transceiver
142
CGND - Ground terminal
143
CVCC18 - Power supply terminal (+1.8V)
144
Q11 O Serial data output to the HDMI transceiver and video processor
