D-VIDEO BOARD IC3513 SII9134CTU (HDMI TRANSCEIVER)
Pin No.
Pin Name I/O Description
1
DE I Data enable signal input from the HDMI receiver
2
HSYNC I Horizontal sync signal input from the HDMI receiver
3
VSYNC I Vertical sync signal input from the HDMI receiver
4
SPDIF I S/PDIF signal input from the HDMI receiver
5
MCLK I Master clock signal input from the HDMI receiver
6 to 9
SD3 to SD0 I PCM audio signal input from the HDMI receiver
10
WS I L/R sampling clock signal input from the HDMI receiver
11
SCK I Bit clock signal input from the HDMI receiver
12
CVCC18 - Power supply terminal (+1.8V)
13
GND - Ground terminal
14
IOVCC33 - Power supply terminal (+3.3V)
15
DCLK I Bit clock signal input from the HDMI receiver
16
DR0 I L/R sampling clock signal input from the HDMI receiver
17 to 20
DL0, DR1,
DL1, DR2
I PCM audio signal input from the HDMI receiver
21
DL2 I S/PDIF signal input from the HDMI receiver
22, 23
DR3, DL3 - Not used
24
INT O Interrupt signal output to the video system controller
25
RESET# I Reset signal input from the video system controller "L": reset
26
AGND - Ground terminal
27
EXT_SWG - Not used
28
PVCC1 - Power supply terminal (+1.8V)
29
AGND - Ground terminal
30
TXC- O TMDS clock (negative) output to the HDMI ASSIGNABLE (INPUT ONLY) OUT jack
31
TXC+ O TMDS clock (positive) output to the HDMI ASSIGNABLE (INPUT ONLY) OUT jack
32
AVCC18 - Power supply terminal (+1.8V)
33
TX0- O TMDS data (negative) output to the HDMI ASSIGNABLE (INPUT ONLY) OUT jack
34
TX0+ O TMDS data (positive) output to the HDMI ASSIGNABLE (INPUT ONLY) OUT jack
35
AGND - Ground terminal
36
TX1- O TMDS data (negative) output to the HDMI ASSIGNABLE (INPUT ONLY) OUT jack
37
TX1+ O TMDS data (positive) output to the HDMI ASSIGNABLE (INPUT ONLY) OUT jack
38
AVCC18 - Power supply terminal (+1.8V)
39
TX2- O TMDS data (negative) output to the HDMI ASSIGNABLE (INPUT ONLY) OUT jack
40
TX2+ O TMDS data (positive) output to the HDMI ASSIGNABLE (INPUT ONLY) OUT jack
41
AGND - Ground terminal
42
PVCC2 - Power supply terminal (+1.8V)
43
AGND - Ground terminal
44
AVCC33 - Power supply terminal (+3.3V)
45
DCCPWR5V I Power supply voltage (+5V) input terminal
46
DSCL O I2C clock signal output to the HDMI ASSIGNABLE (INPUT ONLY) OUT jack
47
DSDA I/O I2C two-way data bus with the HDMI ASSIGNABLE (INPUT ONLY) OUT jack
48
CSCL I I2C clock signal input from the video system controller
49
CSDA I/O
I2C two-way data bus with the EEPROM, HDMI input select, HDMI receiver, video system
controller and D/A converter
50
CI2CA - Not used
51
HPD I Hot plug detection signal input from the HDMI ASSIGNABLE (INPUT ONLY) OUT jack
52
TMODE - Not used
