154
STR-DA5300ES
Pin No.
Pin Name I/O Description
53
IOVCC33 - Power supply terminal (+3.3V)
54
GND - Ground terminal
55
VPP18 - Power supply terminal (+1.8V)
56 to 63
D35 to D28 I Serial data input from the HDMI receiver and video processor
64
CVCC18 - Power supply terminal (+1.8V)
65
GND - Ground terminal
66
IOVCC33 - Power supply terminal (+3.3V)
67 to 70
D27 to D24 I Serial data input from the HDMI receiver
71 to 75
D23 to D19 I Serial data input from the HDMI receiver and video processor
76
CVCC18 - Power supply terminal (+1.8V)
77 to 79
D18 to D16 I Serial data input from the HDMI receiver and video processor
80 to 83
D15 to D12 I Serial data input from the HDMI receiver
84 to 86
D11 to D9 I Serial data input from the HDMI receiver and video processor
87
GND - Ground terminal
88
IDCK I Output data clock signal input from the HDMI receiver
89
IOVCC33 - Power supply terminal (+3.3V)
90 to 94
D8 to D4 I Serial data input from the HDMI receiver and video processor
95 to 98
D3 to D0 I Serial data input from the HDMI receiver
99
CVCC18 - Power supply terminal (+1.8V)
100
GND - Ground terminal
