158
STR-DA5300ES
Pin No.
Pin Name I/O Description
M3
DIP_EXT
_COAST
- Not used
M4
IPCLK2 I Dot clock signal input from the OSD controller
M10 to M17
D_GND - Ground terminal
M23
IO_3.3V - Power supply terminal (+3.3V)
M24, M25
LVDS_GND - Ground terminal
M26
LVDS_3.3V - Power supply terminal (+3.3V)
N1
IPCLK0 I Clock signal input terminal Not used
N2
DIP_RAW_HS_CS
- Not used
N3
DIP_AODD - Not used
N4
DIP_BODD - Not used
N10 to N17
D_GND - Ground terminal
N23 to N26
PD0 to PD3 I/O Serial data input from the HDMI receiver and serial data output to the HDMI transceiver
P1 to P3
ADATA2 to
ADATA0
- Not used
P4
IPCLK1 I Clock signal input terminal Not used
P10 to P17
D_GND - Ground terminal
P23
IO_3.3V - Power supply terminal (+3.3V)
P24
DCLK I Output data clock signal input from the HDMI receiver
P25
DHS I Horizontal sync signal input from the HDMI receiver
P26
DEN I Data enable signal input from the HDMI receiver
R1 to R4
ADATA6 to
ADATA3
- Not used
R10 to R17
D_GND - Ground terminal
R23
JTAG_BS_TDI - Not used
R24
JTAG_BS_RST - Not used
R25
JTAG_BS_TCK - Not used
R26
DVS I Vertical sync signal input from the HDMI receiver
T1 to T4
ADATA10 to
ADATA7
- Not used
T10
D_GND - Ground terminal
T11
CORE_1.8V - Power supply terminal (+1.8V)
T12 to T15
D_GND - Ground terminal
T16, T17
CORE_1.8V - Power supply terminal (+1.8V)
T23
IO_3.3V - Power supply terminal (+3.3V)
T24
JTAG_BS_TMS - Not used
T25
JTAG_BS_TDO - Not used
T26
GPIO_44 - Not used
U1 to U4
ADATA14 to
ADATA11
- Not used
U10, U11
CORE_1.8V - Power supply terminal (+1.8V)
U12 to U15
D_GND - Ground terminal
U16, U17
CORE_1.8V - Power supply terminal (+1.8V)
U23, U24
PWM1, PWM2 - Not used
U25
PPWR - Not used
U26
PBIAS - Not used
V1 to V4
ADATA18 to
ADATA15
- Not used
