159
STR-DA5300ES
Pin No.
Pin Name I/O Description
V23
IO_3.3V - Power supply terminal (+3.3V)
V24
PWM0 - Not used
V25
SLAVE_SDA - Not used
V26
SLAVE_SCL - Not used
W1 to W4
ADATA22 to
ADATA19
- Not used
W23
OCM_INT1 - Not used
W24
OCM_TIMER1 - Not used
W25
OCM_UDI_0 - Not used
W26
ODM_UDO_0 - Not used
Y1
AVS - Not used
Y2
AHS - Not used
Y3
AHREF_DE - Not used
Y4
ADATA23 - Not used
Y23
IO_3.3V - Power supply terminal (+3.3V)
Y24
OCM_INT2 - Not used
Y25
VGA1_SDA - Not used
Y26
VGA1_SCL - Not used
AA1
NC - Not used
AA2 to
AA4
DGND_ADC - Ground terminal
AA23
MSTR0_SDA I/O Two-way data bus with the EEPROM
AA24
MSTR0_SCL O Serial clock signal output to the EEPROM
AA25
VGA0_SDA - Not used
AA26
VGA0_SCL - Not used
AB1
A1P I Video signal input (P
R /C R ) from the COMPONENT VIDEO ASSIGNABLE (INPUT ONLY) jack
AB2
SV1P - Not used
AB3
AGND_ADC - Ground terminal
AB4
ADC_1.8V - Power supply terminal (+1.8V)
AB23
IO_3.3V - Power supply terminal (+3.3V)
AB24
IRO - Not used
AB25
MSTR2_SDA I/O Not used
AB26
MSTR2_SCL O Not used
AC1
C1P I Video signal input (Y) from the COMPONENT VIDEO ASSIGNABLE (INPUT ONLY) jack
AC2
B1P I Video signal input (P
B /C B ) from the COMPONENT VIDEO ASSIGNABLE (INPUT ONLY) jack
AC3
AGND_ADC - Ground terminal
AC4, AC5
ADC_1.8V - Power supply terminal (+1.8V)
AC6
AGND_ADC - Ground terminal
AC7
VOUT2 - Not used
AC8
AGND_ADC - Ground terminal
AC9
LBADC_3.3V - Power supply terminal (+3.3V)
AC10
LBADC_IN4 - Not used
AC11
LBADC_GND - Ground terminal
AC12
AVSIN_DATA - Not used
AC13
EXTOSD_HS - Not used
AC14
IO_3.3V - Power supply terminal (+3.3V)
AC15
OCMADDR18 O Address signal output to the flash memory
AC16
IO_3.3V - Power supply terminal (+3.3V)
