Sony STR-DA5300ES - Page 160

160
STR-DA5300ES
Pin No.
Pin Name I/O Description
AC17
OCMADDR11 O Address signal output to the flash memory
AC18
IO_3.3V - Power supply terminal (+3.3V)
AC19
OCMADDR4 O Address signal output to the flash memory
AC20
IO_3.3V - Power supply terminal (+3.3V)
AC21
OCMDATA13 I/O Two-way data bus with the flash memory
AC22
IO_3.3V - Power supply terminal (+3.3V)
AC23
OCMDATA6 I/O Two-way data bus with the flash memory
AC24
OCM_CS2N O Chip select signal output terminal Not used
AC25
OCN_RE_N O Read enable signal output to the flash memory
AC26
OCN_WE_N O Write enable signal output to the flash memory
AD1
AN - Not used
AD2
AGND_ADC - Ground terminal
AD3 to AD5
ADC1_3.3V - Power supply terminal (+3.3V)
AD6, AD7
ADC2_3.3V - Power supply terminal (+3.3V)
AD8
AGND_ADC - Ground terminal
AD9
RESET
I
Reset signal input from the video system controller "L": reset
AD10
LBADC_IN3 - Not used
AD11
LBADC_RETURN
- Not used
AD12
AVSIN_WORDSEL
- Not used
AD13
EXTOSD_VS - Not used
AD14
AVSOUT_DATA
- Not used
AD15 to
AD20
OCMADDR19,
OCMADDR15,
OCMADDR12,
OCMADDR8,
OCMADDR5,
OCMADDR1
O Address signal output to the flash memory
AD21 to
AD23
OCMDATA14,
OCMDATA10,
OCMDATA7
I/O Two-way data bus with the flash memory
AD24
ROM_CS_N O Chip enable signal output to the flash memory
AD25,
AD26
OCM_CS0N,
OCM_CS1N
O Chip select signal output terminal Not used
AE1
SV2P - Not used
AE2
B2P I Video signal input (C) from the S VIDEO IN jack
AE3
AGND_ADC - Ground terminal
AE4
SV3P - Not used
AE5
B3P I Video signal input (camera) from the EXT VIDEO IN jack
AE6
AGND_ADC - Ground terminal
AE7
SV4P - Not used
AE8
BN2 - Not used
AE9
AGND_ADC - Ground terminal
AE10,
AE11
LBADC_IN2,
LBADC_IN6
- Not used
AE12
AIP_RAW_VS - Not used
AE13
AVSOUT_SCL - Not used
AE14
AVSOUT_
WORDSEL
- Not used
