STR-DA5300ES
D-VIDEO BOARD IC3604 YGV629-VZ (OSD CONTROLLER)
Pin No.
Pin Name I/O Description
1
PLLVDD - Power supply terminal (+3.3V)
2
FILTER I Filter connection terminal for internal PLL
3
PLLVSS - Ground terminal
4
NC - Not used
5 to 10
PLLCTL5 to
PLLCTL0
I PLL setting terminal
11
DTCKS_N I Clock signal input terminal Not used
12
DTCK_IN I Clock signal input terminal Not used
13
VSS - Ground terminal
14
VDD - Power supply terminal (+3.3V)
15 to 22
D0 to D7 I/O Two-way data bus with the video system controller and S-RAM
23
WAIT_N O Wait signal output to the video system controller
24
READY_N - Not used
25
INT_N O Interrupt signal output to the video system controller
26
VDD - Power supply terminal (+3.3V)
27
VSS - Ground terminal
28
CS_N I Chip select signal input from the video system controller
29
WR_N I Write enable signal input from the video system controller
30 RD_N
I Read enable signal input from the video system controller
31 to 33
PS2 to PS0 I Address signal input from the video system controller
34
SDOUT O Serial data output terminal Not used
35
SDIN I Serial data input terminal Not used
36
SCS_N I Chip select signal input terminal Not used
37
SCLK I Serial data transfer clock signal input terminal Not used
38
SER_N I CPU interface select setting terminal Fixed at "H" in this set
39
RESET_N
I
Reset signal input from the video system controller "L": reset
40
VSS - Ground terminal
41
VDD - Power supply terminal (+3.3V)
42
MA0 O Address signal output terminal Not used
43 to 47
MA1 to MA5 O Address signal output to the flash memory
48
VSS - Ground terminal
49 to 54
MA6 to MA11 O Address signal output to the flash memory
55
VDD - Power supply terminal (+3.3V)
56
VSS - Ground terminal
57 to 62
MA12 to MA17 O Address signal output to the flash memory
63
VSS - Ground terminal
64 to 70
MA18 to MA24 O Address signal output to the flash memory
71
VDD - Power supply terminal (+3.3V)
72
VSS - Ground terminal
73
MWE_N O Write enable signal output to the flash memory
74
MOE_N O Output enable signal output to the flash memory
75 to 80
MD15, MD7,
MD14, MD6,
MD13, MD5
I/O Two-way data bus with the flash memory
81
VSS - Ground terminal
82
VDD - Power supply terminal (+3.3V)
