STR-DA5300ES
D-VIDEO BOARD IC3610 MB91F467RA-07A53GUI-X103 (VIDEO SYSTEM CONTROLLER)
Pin No.
Pin Name I/O Description
1
GND - Ground terminal
2 to 5
NO USE - Not used
6
STOP IN
I
AC off detection signal input terminal
7
DAC CLOCK SEL
O
Clock on/off control signal output terminal for the D/A converter
8, 9
EDID_SEL0,
EDID_SEL1
O I2C line selection signal output terminal for the EEPROM
10
NO USE - Not used
11, 12
+3.3V - Power supply terminal (+3.3V)
13
GND - Ground terminal
14
C_1 - Not used
15
YAMAHA
FLASH CE
O Not used
16
NO USE - Not used
17
EXT_ROM CE O Not used
18 YAMAHA CE O
Chip enable signal output to the OSD controller
19 SRAM CE O
Chip enable signal output to the S-RAM
20
NO USE - Not used
21
YAMAHA RESET
O
Reset signal output to the flash memory and OSD controller "L": reset
22
YAMAHA
WAIT_N
I
Wait signal input from the OSD controller
23
YAMAHA
READY_N
I Not used
24
NO USE - Not used
25
SRAM OE,UB,LB/
YAMAHA RD_N/
EXT_ROM OE
O
Read enable signal output to the S-RAM and OSD controller
26
SRAM LB,WE O Lower-byte control signal and write enable signal output to the S-RAM
27
SRAM UB,WE/
YAMAHA WR_N/
EXT_ROM WE
O
Upper-byte control signal and write enable signal output to the S-RAM, and write enable signal
output to the OSD controller
28, 29
NO USE - Not used
30
TX_RST
O
Reset signal output to the HDMI transceiver "L": reset
31
TX_5VPWR O
Power on/off control signal output terminal for the HDMI ASSIGNABLE (INPUT ONLY) OUT
jack "H": power on
32
VDAC_RESET
O
Reset signal output to the D/A converter "L": reset
33, 34
NO USE - Not used
35
RX_RST
O
Reset signal output to the HDMI receiver "L": reset
36
+3.3V - Power supply terminal (+3.3V)
37
C_2 - Not used
38
GND - Ground terminal
39
X0 I System clock input terminal (4 MHz)
40
X1 O System clock output terminal (4 MHz)
41
GND - Ground terminal
42
X0A I System clock input terminal Not used
43
X1A O System clock output terminal Not used
44
+3.3V - Power supply terminal (+3.3V)
45
GND - Ground terminal
