STR-DA5300ES
Pin No.
Pin Name I/O Description
117
UC3V_SDA I/O
I2C two-way data bus with the EEPROM, HDMI input select, HDMI receiver, HDMI transceiver
and D/A converter
118
UC3V_SCL O
I2C clock signal output to the EEPROM, HDMI input select, HDMI receiver, HDMI transceiver
and D/A converter
119
YAMAHA_INT_N
I Interrupt signal input from the OSD controller
120
NO USE - Not used
121
RX_INT I Interrupt signal input from the HDMI receiver
122
NO USE - Not used
123
TX_INT I Interrupt signal input from the HDMI transceiver
124
NO USE - Not used
125
Faroudja Power
DETECT
I Power detection signal input from the video processor
126
Faroudja UCOM
RESET
O
Reset signal output to the video processor and flash memory "L": reset
127 MD3 -
Mode setting terminal Fixed at "L" in this set
128 MD2 I
Programming mode signal input from the system controller
129, 130 MD1, MD0 -
Mode setting terminal Fixed at "L" in this set
131 INITX I
Reset signal input from the system controller "L": reset
132
GND - Ground terminal
133
+5V - Power supply terminal (+3.3V)
134
Flash Update RX
I
Serial data input terminal
135
Flash Update TX
O
Serial data output terminal
136
ENDFLAG
I
Programming end flag input from the system controller
137
MAIN UCOM
UART RX
I Serial data input from the system controller
138
MAIN UCOM
UART TX
O Serial data output to the system controller
139
MAIN UCOM
UART BUSY
I Busy signal input from the system controller
140
Faroudja UCOM
UART RX
I
UART communication transfer data input from the video processor
141
Faroudja UCOM
UART TX
O
UART communication transfer data output to the video processor
142
Faroudja UCOM
BUSY
O
Busy signal output to the video processor
143 to 145
NO USE - Not used
146
GND - Ground terminal
147
+5V - Power supply terminal (+3.3V)
148 to 160
NO USE - Not used
161
GND - Ground terminal
162
+5V - Power supply terminal (+3.3V)
163 to 167
NO USE - Not used
168
V.SYNC_DET I Vertical sync signal input terminal Not used
169 to 175
NO USE - Not used
176
+5V - Power supply terminal (+3.3V)
