Sony STR-DA5300ES - Page 220

Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
220
STR-DA5300ES
< TERMINAL >
TM4001 1-780-405-11 TERMINAL BOARD (SP) (2P) (CENTER
SPEAKERS)
TM4002 1-780-404-11 TERMINAL BOARD (SP) (8P) (FRONT A/B
SPEAKERS)
************************************************************
MAIN VOL BOARD
**************
< CONNECTOR >
* CN712 1-564-720-11 PIN, CONNECTOR (SMALL TYPE) 4P
< ROTARY ENCODER >
S722 1-418-725-41 ENCODER, ROTARY (12 TYPE) (MASTER
VOLUME)
************************************************************
MIC BOARD
**********
< CAPACITOR >
C755 1-164-230-11 CERAMIC CHIP 220PF 5% 50V
< CONNECTOR >
CN718 1-564-719-11 PIN, CONNECTOR (SMALL TYPE) 3P
< DIODE >
D717 8-719-404-50 DIODE MA111-TX
D718 8-719-404-50 DIODE MA111-TX
< JACK >
J701 1-820-056-11 SMALL TYPE JACK (AUTO CAL MIC)
< LEAD >
W701 1-775-377-21 LEAD (WITH CONNECTOR)
************************************************************
A-1252-362-A POWER AMPLIFIER BOARD, COMPLETE
(US, CND)
A-1252-571-A POWER AMPLIFIER BOARD, COMPLETE
(AEP, ECE, UK)
********************************
< CAPACITOR >
C1512 1-107-597-11 CERAMIC 22PF 5% 500V
C1513 1-107-597-11 CERAMIC 22PF 5% 500V
C1562 1-107-597-11 CERAMIC 22PF 5% 500V
C1563 1-107-597-11 CERAMIC 22PF 5% 500V
C1612 1-107-597-11 CERAMIC 22PF 5% 500V
C1613 1-107-597-11 CERAMIC 22PF 5% 500V
C1712 1-107-597-11 CERAMIC 22PF 5% 500V
C1713 1-107-597-11 CERAMIC 22PF 5% 500V
C1762 1-107-597-11 CERAMIC 22PF 5% 500V
C1763 1-107-597-11 CERAMIC 22PF 5% 500V
C1812 1-107-597-11 CERAMIC 22PF 5% 500V
C1813 1-107-597-11 CERAMIC 22PF 5% 500V
C1862 1-107-597-11 CERAMIC 22PF 5% 500V
C1863 1-107-597-11 CERAMIC 22PF 5% 500V
C1903 1-112-857-21 ELECT 100uF 20% 100V
(AEP, UK)
C1903 1-128-563-11 ELECT 100uF 20% 100V
(US, CND)
C1904 1-112-857-21 ELECT 100uF 20% 100V
(AEP, UK)
C1904 1-128-563-11 ELECT 100uF 20% 100V
(US, CND)
< CONNECTOR >
CN1510 1-573-846-11 CONNECTOR, BOARD TO BOARD 14P
CN1572 1-766-600-21 CONNECTOR, BOARD TO BOARD 7P
CN1703 1-573-846-11 CONNECTOR, BOARD TO BOARD 14P
CN1872 1-573-846-11 CONNECTOR, BOARD TO BOARD 14P
CN1901 1-785-102-11 PIN, CONNECTOR (3.96mm PITCH) 4P
CN1903 1-573-844-11 CONNECTOR, BOARD TO BOARD 12P
CN1904 1-573-844-11 CONNECTOR, BOARD TO BOARD 12P
< COIL >
L1501 1-420-872-52 COIL, AIR-CORE
L1551 1-420-872-52 COIL, AIR-CORE
L1601 1-420-872-52 COIL, AIR-CORE
L1701 1-420-872-52 COIL, AIR-CORE
L1751 1-420-872-52 COIL, AIR-CORE
L1801 1-420-872-52 COIL, AIR-CORE
L1851 1-420-872-52 COIL, AIR-CORE
< RESISTOR >
0R1515 1-249-405-11 CARBON 100 5% 1/4W F
0R1516 1-234-572-21 ENCAPSULATED COMPONENT 0.22 5W F
0R1517 1-249-405-11 CARBON 100 5% 1/4W F
0R1518 1-249-393-11 CARBON 10 5% 1/4W F
0R1565 1-249-405-11 CARBON 100 5% 1/4W F
0R1566 1-234-572-21 ENCAPSULATED COMPONENT 0.22 5W F
0R1567 1-249-405-11 CARBON 100 5% 1/4W F
0R1568 1-249-393-11 CARBON 10 5% 1/4W F
0R1615 1-249-405-11 CARBON 100 5% 1/4W F
0R1616 1-234-572-21 ENCAPSULATED COMPONENT 0.22 5W F
0R1617 1-249-405-11 CARBON 100 5% 1/4W F
0R1618 1-249-393-11 CARBON 10 5% 1/4W F
0R1715 1-249-405-11 CARBON 100 5% 1/4W F
0R1716 1-234-572-21 ENCAPSULATED COMPONENT 0.22 5W F
0R1717 1-249-405-11 CARBON 100 5% 1/4W F
0R1718 1-249-393-11 CARBON 10 5% 1/4W F
0R1765 1-249-405-11 CARBON 100 5% 1/4W F
0R1766 1-234-572-21 ENCAPSULATED COMPONENT 0.22 5W F
0R1767 1-249-405-11 CARBON 100 5% 1/4W F
0R1768 1-249-393-11 CARBON 10 5% 1/4W F
0R1815 1-249-405-11 CARBON 100 5% 1/4W F
0R1816 1-234-572-21 ENCAPSULATED COMPONENT 0.22 5W F
0R1817 1-249-405-11 CARBON 100 5% 1/4W F
0R1818 1-249-393-11 CARBON 10 5% 1/4W F
MAIN VOL MIC POWER AMPLIFIERMAIN
Ver. 1.1
