Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
221
STR-DA5300ES
0R1865 1-249-405-11 CARBON 100 5% 1/4W F
0R1866 1-234-572-21 ENCAPSULATED COMPONENT 0.22 5W F
0R1867 1-249-405-11 CARBON 100 5% 1/4W F
0R1868 1-249-393-11 CARBON 10 5% 1/4W F
************************************************************
A-1252-367-A PROTECTOR (F-C) BOARD, COMPLETE
*******************************
< CAPACITOR >
C1522 1-128-813-11 CERAMIC 220PF 5% 50V
C1523 1-136-153-00 MYLAR 0.01uF 5% 50V
C1524 1-126-964-11 ELECT 10uF 20% 50V
C1572 1-128-813-11 CERAMIC 220PF 5% 50V
C1573 1-136-153-00 MYLAR 0.01uF 5% 50V
C1574 1-126-964-11 ELECT 10uF 20% 50V
C1622 1-128-813-11 CERAMIC 220PF 5% 50V
C1623 1-136-153-00 MYLAR 0.01uF 5% 50V
C1624 1-126-964-11 ELECT 10uF 20% 50V
< CONNECTOR >
CN1501 1-766-715-21 CONNECTOR, BOARD TO BOARD 10P
* CN1503 1-774-876-21 CONNECTOR, BOARD TO BOARD 8P
* CN1521 1-573-828-11 CONNECTOR, BOARD TO BOARD 14P
* CN1561 1-564-720-11 PIN, CONNECTOR (SMALL TYPE) 4P
CN1571 1-766-724-11 CONNECTOR, BOARD TO BOARD 7P
* CN1611 1-564-720-11 PIN, CONNECTOR (SMALL TYPE) 4P
< DIODE >
D1521 8-719-991-33 DIODE 1SS133T-77
D1522 8-719-991-33 DIODE 1SS133T-77
D1571 8-719-991-33 DIODE 1SS133T-77
D1572 8-719-991-33 DIODE 1SS133T-77
D1621 8-719-991-33 DIODE 1SS133T-77
D1622 8-719-991-33 DIODE 1SS133T-77
< TRANSISTOR >
Q1522 8-729-042-09 TRANSISTOR 2SA1038S-RSE-TP
Q1523 8-729-042-09 TRANSISTOR 2SA1038S-RSE-TP
Q1524 8-729-119-78 TRANSISTOR 2SC2785-HFE
Q1572 8-729-042-09 TRANSISTOR 2SA1038S-RSE-TP
Q1573 8-729-042-09 TRANSISTOR 2SA1038S-RSE-TP
Q1574 8-729-119-78 TRANSISTOR 2SC2785-HFE
Q1622 8-729-042-09 TRANSISTOR 2SA1038S-RSE-TP
Q1623 8-729-042-09 TRANSISTOR 2SA1038S-RSE-TP
Q1624 8-729-119-78 TRANSISTOR 2SC2785-HFE
< RESISTOR >
R1525 1-247-874-91 CARBON 4.7K 5% 1/4W
0R1526 1-240-855-91 CARBON 6.2K 5% 1/4W F
R1527 1-249-420-11 CARBON 1.8K 5% 1/4W
R1528 1-249-431-11 CARBON 15K 5% 1/4W
R1529 1-247-862-11 CARBON 20K 5% 1/4W
R1530 1-249-419-11 CARBON 1.5K 5% 1/4W
R1531 1-247-871-91 CARBON 47K 5% 1/4W
R1532 1-249-431-11 CARBON 15K 5% 1/4W
R1533 1-247-871-91 CARBON 47K 5% 1/4W
R1534 1-247-863-91 CARBON 22K 5% 1/4W
R1535 1-249-439-11 CARBON 68K 5% 1/4W
R1536 1-247-887-00 CARBON 220K 5% 1/4W
R1575 1-247-847-91 CARBON 4.7K 5% 1/4W
0R1576 1-240-855-91 CARBON 6.2K 5% 1/4W F
R1577 1-249-420-11 CARBON 1.8K 5% 1/4W
R1578 1-249-431-11 CARBON 15K 5% 1/4W
R1579 1-247-862-11 CARBON 20K 5% 1/4W
R1580 1-249-419-11 CARBON 1.5K 5% 1/4W
R1581 1-247-871-91 CARBON 47K 5% 1/4W
R1582 1-249-431-11 CARBON 15K 5% 1/4W
R1583 1-247-871-91 CARBON 47K 5% 1/4W
R1584 1-247-863-91 CARBON 22K 5% 1/4W
R1585 1-249-439-11 CARBON 68K 5% 1/4W
R1586 1-247-887-00 CARBON 220K 5% 1/4W
R1625 1-247-847-91 CARBON 4.7K 5% 1/4W
0R1626 1-240-855-91 CARBON 6.2K 5% 1/4W F
R1627 1-249-420-11 CARBON 1.8K 5% 1/4W
R1628 1-249-431-11 CARBON 15K 5% 1/4W
R1629 1-247-862-11 CARBON 20K 5% 1/4W
R1630 1-249-419-11 CARBON 1.5K 5% 1/4W
R1631 1-247-871-91 CARBON 47K 5% 1/4W
R1632 1-249-431-11 CARBON 15K 5% 1/4W
R1633 1-247-871-91 CARBON 47K 5% 1/4W
R1634 1-247-863-91 CARBON 22K 5% 1/4W
R1635 1-249-439-11 CARBON 68K 5% 1/4W
R1636 1-247-887-00 CARBON 220K 5% 1/4W
************************************************************
A-1252-369-A PROTECTOR (SB) BOARD, COMPLETE
******************************
< CAPACITOR >
C1822 1-128-813-11 CERAMIC 220PF 5% 50V
C1823 1-136-153-00 MYLAR 0.01uF 5% 50V
C1824 1-126-964-11 ELECT 10uF 20% 50V
C1872 1-128-813-11 CERAMIC 220PF 5% 50V
C1873 1-136-153-00 MYLAR 0.01uF 5% 50V
C1874 1-126-964-11 ELECT 10uF 20% 50V
< CONNECTOR >
CN1801 1-573-846-11 CONNECTOR, BOARD TO BOARD 14P
* CN1861 1-564-720-11 PIN, CONNECTOR (SMALL TYPE) 4P
* CN1871 1-573-828-11 CONNECTOR, BOARD TO BOARD 14P
< DIODE >
D1821 8-719-991-33 DIODE 1SS133T-77
D1822 8-719-991-33 DIODE 1SS133T-77
D1871 8-719-991-33 DIODE 1SS133T-77
D1872 8-719-991-33 DIODE 1SS133T-77
< TRANSISTOR >
Q1822 8-729-042-09 TRANSISTOR 2SA1038S-RSE-TP
Q1823 8-729-042-09 TRANSISTOR 2SA1038S-RSE-TP
Q1824 8-729-119-78 TRANSISTOR 2SC2785-HFE
Q1872 8-729-042-09 TRANSISTOR 2SA1038S-RSE-TP
Q1873 8-729-042-09 TRANSISTOR 2SA1038S-RSE-TP
POWER AMPLIFIER PROTECTOR (F-C) PROTECTOR (SB)
