Sony STR-DA5300ES - Page 222

Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
222
STR-DA5300ES
Q1874 8-729-119-78 TRANSISTOR 2SC2785-HFE
< RESISTOR >
R1825 1-247-847-91 CARBON 4.7K 5% 1/4W
0R1826 1-240-855-91 CARBON 6.2K 5% 1/4W F
R1827 1-249-420-11 CARBON 1.8K 5% 1/4W
R1828 1-249-431-11 CARBON 15K 5% 1/4W
R1829 1-247-862-11 CARBON 20K 5% 1/4W
R1830 1-249-419-11 CARBON 1.5K 5% 1/4W
R1831 1-247-871-91 CARBON 47K 5% 1/4W
R1832 1-249-431-11 CARBON 15K 5% 1/4W
R1833 1-247-871-91 CARBON 47K 5% 1/4W
R1834 1-247-863-91 CARBON 22K 5% 1/4W
R1835 1-249-439-11 CARBON 68K 5% 1/4W
R1836 1-247-887-00 CARBON 220K 5% 1/4W
R1875 1-247-847-91 CARBON 4.7K 5% 1/4W
0R1876 1-240-855-91 CARBON 6.2K 5% 1/4W F
R1877 1-249-420-11 CARBON 1.8K 5% 1/4W
R1878 1-249-431-11 CARBON 15K 5% 1/4W
R1879 1-247-862-11 CARBON 20K 5% 1/4W
R1880 1-249-419-11 CARBON 1.5K 5% 1/4W
R1881 1-247-871-91 CARBON 47K 5% 1/4W
R1882 1-249-431-11 CARBON 15K 5% 1/4W
R1883 1-247-871-91 CARBON 47K 5% 1/4W
R1884 1-247-863-91 CARBON 22K 5% 1/4W
R1885 1-249-439-11 CARBON 68K 5% 1/4W
R1886 1-247-887-00 CARBON 220K 5% 1/4W
************************************************************
A-1252-368-A PROTECTOR (SURR) BOARD, COMPLETE
*********************************
< CAPACITOR >
C1722 1-128-813-11 CERAMIC 220PF 5% 50V
C1723 1-136-153-00 MYLAR 0.01uF 5% 50V
C1724 1-126-964-11 ELECT 10uF 20% 50V
C1772 1-128-813-11 CERAMIC 220PF 5% 50V
C1773 1-136-153-00 MYLAR 0.01uF 5% 50V
C1774 1-126-964-11 ELECT 10uF 20% 50V
< CONNECTOR >
* CN1701 1-573-828-11 CONNECTOR, BOARD TO BOARD 14P
CN1704 1-573-846-11 CONNECTOR, BOARD TO BOARD 14P
* CN1761 1-564-720-11 PIN, CONNECTOR (SMALL TYPE) 4P
< DIODE >
D1721 8-719-991-33 DIODE 1SS133T-77
D1722 8-719-991-33 DIODE 1SS133T-77
D1771 8-719-991-33 DIODE 1SS133T-77
D1772 8-719-991-33 DIODE 1SS133T-77
< TRANSISTOR >
Q1722 8-729-042-09 TRANSISTOR 2SA1038S-RSE-TP
Q1723 8-729-042-09 TRANSISTOR 2SA1038S-RSE-TP
Q1724 8-729-119-78 TRANSISTOR 2SC2785-HFE
Q1772 8-729-042-09 TRANSISTOR 2SA1038S-RSE-TP
Q1773 8-729-042-09 TRANSISTOR 2SA1038S-RSE-TP
Q1774 8-729-119-78 TRANSISTOR 2SC2785-HFE
< RESISTOR >
R1725 1-247-847-91 CARBON 4.7K 5% 1/4W
0R1726 1-240-855-91 CARBON 6.2K 5% 1/4W F
R1727 1-249-420-11 CARBON 1.8K 5% 1/4W
R1728 1-249-431-11 CARBON 15K 5% 1/4W
R1729 1-247-862-11 CARBON 20K 5% 1/4W
R1730 1-249-419-11 CARBON 1.5K 5% 1/4W
R1731 1-247-871-91 CARBON 47K 5% 1/4W
R1732 1-249-431-11 CARBON 15K 5% 1/4W
R1733 1-247-871-91 CARBON 47K 5% 1/4W
R1734 1-247-863-91 CARBON 22K 5% 1/4W
R1735 1-249-439-11 CARBON 68K 5% 1/4W
R1736 1-247-887-00 CARBON 220K 5% 1/4W
R1775 1-247-847-91 CARBON 4.7K 5% 1/4W
0R1776 1-240-855-91 CARBON 6.2K 5% 1/4W F
R1777 1-249-420-11 CARBON 1.8K 5% 1/4W
R1778 1-249-431-11 CARBON 15K 5% 1/4W
R1779 1-247-862-11 CARBON 20K 5% 1/4W
R1780 1-249-419-11 CARBON 1.5K 5% 1/4W
R1781 1-247-871-91 CARBON 47K 5% 1/4W
R1782 1-249-431-11 CARBON 15K 5% 1/4W
R1783 1-247-871-91 CARBON 47K 5% 1/4W
R1784 1-247-863-91 CARBON 22K 5% 1/4W
R1785 1-249-439-11 CARBON 68K 5% 1/4W
R1786 1-247-887-00 CARBON 220K 5% 1/4W
************************************************************
A-1252-348-A S-VIDEO BOARD, COMPLETE
***********************
< CAPACITOR >
C6902 1-162-923-11 CERAMIC CHIP 47PF 5% 50V
C6904 1-162-923-11 CERAMIC CHIP 47PF 5% 50V
C6906 1-126-964-11 ELECT 10uF 20% 50V
C6907 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V
C6908 1-126-964-11 ELECT 10uF 20% 50V
C6909 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V
C6910 1-126-964-11 ELECT 10uF 20% 50V
C6911 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V
C6912 1-126-964-11 ELECT 10uF 20% 50V
C6913 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V
C6915 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V
C6916 1-126-964-11 ELECT 10uF 20% 50V
C6917 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C6918 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C6919 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C6920 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C6921 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V
C6922 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V
C6923 1-126-947-11 ELECT 47uF 20% 35V
C6924 1-126-947-11 ELECT 47uF 20% 35V
C6925 1-162-923-11 CERAMIC CHIP 47PF 5% 50V
C6926 1-162-923-11 CERAMIC CHIP 47PF 5% 50V
< CONNECTOR >
CN6903 1-779-289-11 CONNECTOR, FFC (LIF (NON-ZIF)) 21P
PROTECTOR (SB) PROTECTOR (SURR) S-VIDEO
