Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
223
STR-DA5300ES
CN6904 1-779-977-11 PIN, CONNECTOR 6P
< FERRITE BEAD >
FB6901 1-469-152-11 FERRITE, EMI (SMD) (2012)
FB6902 1-469-152-11 FERRITE, EMI (SMD) (2012)
< IC >
IC6901 6-704-199-01 IC NJM2595M-TE2
IC6902 6-704-199-01 IC NJM2595M-TE2
< JACK >
J6901 1-764-676-11 CONNECTOR (ROUND TYPE) (SAT/CATV/DVD/
BD S VIDEO IN)
J6902 1-764-676-11 CONNECTOR (ROUND TYPE) (VIDEO 2 S VIDEO
IN, VIDEO 1 S VIDEO OUT)
J6903 1-764-676-11 CONNECTOR (ROUND TYPE) (VIDEO 1 S VIDEO
IN, MONITOR S VIDEO OUT)
J6904 1-774-227-11 JACK, PIN 1P (EXT VIDEO IN)
< RESISTOR >
R6901 1-211-990-11 METAL CHIP 75 0.5% 1/10W
R6902 1-211-990-11 METAL CHIP 75 0.5% 1/10W
R6903 1-211-990-11 METAL CHIP 75 0.5% 1/10W
R6904 1-211-990-11 METAL CHIP 75 0.5% 1/10W
R6906 1-211-990-11 METAL CHIP 75 0.5% 1/10W
R6907 1-211-990-11 METAL CHIP 75 0.5% 1/10W
R6908 1-211-990-11 METAL CHIP 75 0.5% 1/10W
R6909 1-211-990-11 METAL CHIP 75 0.5% 1/10W
R6910 1-211-990-11 METAL CHIP 75 0.5% 1/10W
R6911 1-216-864-11 SHORT CHIP 0
R6912 1-216-864-11 SHORT CHIP 0
R6915 1-211-990-11 METAL CHIP 75 0.5% 1/10W
R6916 1-211-990-11 METAL CHIP 75 0.5% 1/10W
R6922 1-216-845-11 METAL CHIP 100K 5% 1/10W
R6923 1-216-845-11 METAL CHIP 100K 5% 1/10W
R6924 1-216-845-11 METAL CHIP 100K 5% 1/10W
R6925 1-216-845-11 METAL CHIP 100K 5% 1/10W
R6926 1-216-845-11 METAL CHIP 100K 5% 1/10W
R6927 1-216-864-11 SHORT CHIP 0
R6928 1-216-864-11 SHORT CHIP 0
R6929 1-211-990-11 METAL CHIP 75 0.5% 1/10W
R6930 1-211-990-11 METAL CHIP 75 0.5% 1/10W
R6931 1-211-990-11 METAL CHIP 75 0.5% 1/10W
R6932 1-211-990-11 METAL CHIP 75 0.5% 1/10W
************************************************************
A-1252-308-A SP-TM BOARD, COMPLETE
**********************
< CAPACITOR >
C4101 1-137-395-91 MYLAR 0.022uF 5% 100V
C4102 1-137-395-91 MYLAR 0.022uF 5% 100V
C4103 1-137-395-91 MYLAR 0.022uF 5% 100V
C4104 1-137-395-91 MYLAR 0.022uF 5% 100V
C4105 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C4106 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C4107 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C4108 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
< CONNECTOR >
CX4101 1-785-105-11 PIN, CONNECTOR (3.96mm PITCH) 7P
CX4102 1-785-104-11 PIN, CONNECTOR (3.96mm PITCH) 6P
CX4103 1-784-921-11 PIN, CONNECTOR 4P
CX4104 1-785-101-11 PIN, CONNECTOR (3.96mm PITCH) 3P
< DIODE >
D4101 6-501-193-01 DIODE 1SS355WTE-17
D4102 6-501-193-01 DIODE 1SS355WTE-17
< TRANSISTOR >
Q4101 8-729-230-49 TRANSISTOR 2SC2712-YG
Q4102 8-729-230-49 TRANSISTOR 2SC2712-YG
< RESISTOR >
R4101 1-208-445-41 RES-CHIP 2.2K 2% 1/10W
R4102 1-208-445-41 RES-CHIP 2.2K 2% 1/10W
0R4103 1-249-393-11 CARBON 10 5% 1/4W F
R4104 1-208-462-41 RES-CHIP 10K 2% 1/10W
0R4105 1-249-393-11 CARBON 10 5% 1/4W F
R4106 1-208-462-41 RES-CHIP 10K 2% 1/10W
0R4107 1-249-393-11 CARBON 10 5% 1/4W F
0R4108 1-249-393-11 CARBON 10 5% 1/4W F
0R4109 1-249-393-11 CARBON 10 5% 1/4W F
0R4110 1-249-393-11 CARBON 10 5% 1/4W F
< RELAY >
RY4101 1-515-920-11 RELAY (24V)
RY4102 1-515-920-11 RELAY (24V)
< TERMINAL >
TM4101 1-780-404-11 TERMINAL BOARD (SP) (8P) (SURROUND/
SURROUND BACK (ZONE 2) SPEAKERS)
************************************************************
A-1252-357-A SPSW BOARD, COMPLETE
*********************
< DIODE >
D711 8-719-404-50 DIODE MA111-TX
D712 8-719-404-50 DIODE MA111-TX
< RESISTOR >
R780 1-216-025-11 RES-CHIP 100 5% 1/10W
R781 1-216-025-11 RES-CHIP 100 5% 1/10W
R782 1-216-089-91 RES-CHIP 47K 5% 1/10W
R783 1-216-089-91 RES-CHIP 47K 5% 1/10W
< SWITCH >
S724 1-762-684-11 SWITCH, ROTARY (SPEAKERS)
************************************************************
TEMPERATURE DETECTION BOARD
*****************************
< CAPACITOR >
C1909 1-127-888-11 CERAMIC 0.1uF 10% 50V
C1910 1-135-800-11 CERAMIC 1uF 50V
S-VIDEO SP-TM SPSW TEMPERATURE DETECTION
