Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
224
STR-DA5300ES
C1913 1-135-800-11 CERAMIC 1uF 50V
< DIODE >
D1906 8-719-109-93 DIODE RD6.2ESB2
< IC >
IC1903 6-710-072-01 IC LM61CIZ/LFT2
IC1905 6-710-072-01 IC LM61CIZ/LFT2
< RESISTOR >
R1928 1-249-414-11 CARBON 560 5% 1/4W
************************************************************
VIDEO3 BOARD
************
< CAPACITOR >
C757 1-104-665-11 ELECT 100uF 20% 25V
C758 1-104-665-11 ELECT 100uF 20% 25V
C759 1-163-025-11 CERAMIC CHIP 0.001uF 50V
C760 1-163-025-11 CERAMIC CHIP 0.001uF 50V
C761 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C762 1-163-021-91 CERAMIC CHIP 0.01uF 10% 50V
C763 1-163-021-91 CERAMIC CHIP 0.01uF 10% 50V
C764 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C765 1-163-139-00 CERAMIC CHIP 820PF 5% 50V
C766 1-163-139-00 CERAMIC CHIP 820PF 5% 50V
C767 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C768 1-163-259-91 CERAMIC CHIP 220PF 5% 50V
C769 1-163-259-91 CERAMIC CHIP 220PF 5% 50V
< TERMINAL/CONNECTOR >
CN720 1-784-808-11 TERMINAL, S (VIDEO 3 IN/PORTABLE AV IN S
VIDEO)
CN721 1-784-923-11 PIN, CONNECTOR 7P
CN723 1-779-978-11 PIN, CONNECTOR 3P
CN724 1-779-977-11 PIN, CONNECTOR 6P
CN725 1-784-922-11 PIN, CONNECTOR 5P
< DIODE >
D713 8-719-404-50 DIODE MA111-TX
D714 8-719-404-50 DIODE MA111-TX
D715 8-719-404-50 DIODE MA111-TX
D716 8-719-404-50 DIODE MA111-TX
< EARTH TERMINAL >
* ET702 1-537-738-21 TERMINAL, EARTH
* ET703 1-537-738-21 TERMINAL, EARTH
< IC >
IC706 8-759-710-97 IC NJM4565M-D
IC707 6-600-219-01 IC GP1FM313RZ0F (VIDEO 3 IN/
PORTABLE AV IN DIGITAL (OPT))
< JACK >
J702 1-815-313-11 JACK (PHONES)
J703 1-770-571-11 JACK BLOCK, PIN (L TYPE) 3P (VIDEO 3 IN/
PORTABLE AV IN AUDIO/VIDEO)
< RESISTOR >
R762 1-216-025-11 RES-CHIP 100 5% 1/10W
R763 1-216-049-11 RES-CHIP 1K 5% 1/10W
R764 1-216-049-11 RES-CHIP 1K 5% 1/10W
R765 1-211-990-11 METAL CHIP 75 0.5% 1/10W
R766 1-211-990-11 METAL CHIP 75 0.5% 1/10W
R767 1-211-990-11 METAL CHIP 75 0.5% 1/10W
R768 1-216-089-91 RES-CHIP 47K 5% 1/10W
R769 1-216-089-91 RES-CHIP 47K 5% 1/10W
R770 1-216-295-91 SHORT CHIP 0
R774 1-216-295-91 SHORT CHIP 0
R775 1-216-295-91 SHORT CHIP 0
R776 1-216-295-91 SHORT CHIP 0
R785 1-216-295-91 SHORT CHIP 0
R786 1-216-295-91 SHORT CHIP 0
************************************************************
MISCELLANEOUS
***************
2 1-500-386-11 FILTER, CLAMP (FERRITE CORE) (US, CND)
52 1-693-728-11 TUNER (FM/AM) (US, CND)
52 1-693-737-11 TUNER (FM/AM) (AEP, ECE, UK)
155 1-543-793-41 FILTER, CLAMP (FERRITE CORE) (US, CND)
* 163 1-543-830-11 CLAMP, SLEEVE FERRITE (US, CND)
253 1-828-367-51 WIRE (FLAT TYPE) (21 CORE)
301 1-823-669-51 WIRE (FLAT TYPE) (11 CORE) (AEP, ECE, UK)
301 1-828-956-51 WIRE (FLAT TYPE) (9 CORE) (US, CND)
403 1-500-386-11 FILTER, CLAMP (FERRITE CORE)
0F001 1-532-504-33 FUSE (T4AL/250V) (AEP, ECE, UK)
0F001 1-533-311-12 FUSE, GLASS CYLINDRICAL (DIA.5) (8A/125V)
(US, CND)
0F1403 1-532-504-33 FUSE (T4AL/250V)
0F1404 1-532-504-33 FUSE (T4AL/250V)
0F1405 1-532-506-33 FUSE (T6.3AL/250V)
0J01 1-821-082-21 INLET, AC 2P (- AC IN)
Q1507 8-729-051-92 TRANSISTOR 2SD2560
Q1508 8-729-051-93 TRANSISTOR 2SB1647
Q1521 8-729-026-08 TRANSISTOR 2SC4495
Q1557 8-729-051-92 TRANSISTOR 2SD2560
Q1558 8-729-051-93 TRANSISTOR 2SB1647
Q1571 8-729-026-08 TRANSISTOR 2SC4495
Q1607 8-729-051-92 TRANSISTOR 2SD2560
Q1608 8-729-051-93 TRANSISTOR 2SB1647
Q1621 8-729-026-08 TRANSISTOR 2SC4495
Q1707 8-729-051-92 TRANSISTOR 2SD2560
Q1708 8-729-051-93 TRANSISTOR 2SB1647
Q1721 8-729-026-08 TRANSISTOR 2SC4495
Q1757 8-729-051-92 TRANSISTOR 2SD2560
Q1758 8-729-051-93 TRANSISTOR 2SB1647
Q1771 8-729-026-08 TRANSISTOR 2SC4495
Q1807 8-729-051-92 TRANSISTOR 2SD2560
Q1808 8-729-051-93 TRANSISTOR 2SB1647
Q1821 8-729-026-08 TRANSISTOR 2SC4495
Q1857 8-729-051-92 TRANSISTOR 2SD2560
Q1858 8-729-051-93 TRANSISTOR 2SB1647
Q1871 8-729-026-08 TRANSISTOR 2SC4495
0T001 1-445-238-11 TRANSFORMER, POWER (US, CND)
VIDEO3TEMPERATURE DETECTION
Ver. 1.1
