29
STR-DA5300ES
Items Display Remark
Super reset SUPER RESET [XXX] Not used for the servicing
If super reset is performed, “up convert signal level adjustment” will also be
initialized
When EEPROM initialization is required, perform the “memory clearing
mode”
RAM watch menu XXX XXX: For monitor of various internal RAM (for design evaluation)
EERROM debug EEPROM [****] [XX] ****: EEPROM address, XX: EEPROM data
Protector on/off PROTECTOR ON/OFF [XXX] XXX: ON or OFF
Model/destination change MODEL [##### * * * *] X X #####: Model, ****: Destination, XX: At or fx
Audio swap SWAP [XXXXXXXXXXX] Switching with M m button of the remote commander
Decoder select DECODER SEL [XXXX] XXXX: AUTO, LEGACY, DDPLUS, TRUEHD, DTSEXP, MP3SUR (for
debug)
Volume value display (FL/FR) FL**** FR XXXX ****: Front L-ch volume value, XXXX: Front R-ch volume value
Volume value display (SL/SR) SL**** SR XXXX ****: Surround L-ch volume value, XXXX: Surround R-ch volume value
Volume value display (CT/SW) CT**** SW XXXX ****: Center volume value, XXXX: Sub woofer volume value
Volume value display (SBL/SBR) SBL**** SBR XXXX ****: Surround back L-ch volume value, XXXX: Surround back R-ch
volume value
DAC mute information disclosure 1 DAC MUTE U XXXXXXXX Display of module information to demand muting in system controller (for
design evaluation)
DAC mute information disclosure 2 DAC MUTE L XXXXXXXX Display of module information to demand muting in system controller (for
design evaluation)
2nd volume value display 2nd VOLUME XXX XXX: 2nd room volume value (00 to ∞)
FL display duty change DARK OUT DUTY [XXX%] XXX: Duty value of FL display (0% to 100%)
DMPORT debug DMP KEY DEBUG [XXX] XXX: ON or OFF (for debug)
Bus overflow debug HA link OVERFLOW HAL R [XX] XX: Counter of overflow receive buffer
(receive)
Bus overflow debug HA link OVERFLOW HAL S [XX] XX: Counter of overflow transmit buffer
(transmit)
Bus overflow debug DMPORT OVERFLOW CLA [XX] XX: Counter of overflow CLA transmit buffer
