STR-DA5500ES
146
Pin No. Pin Name I/O Description
139 R3X0+ I TMDS data (positive) input from the HDMI IN 1 connector
140 R3X1– I TMDS data (negative) input from the HDMI IN 1 connector
141 R3X1+ I TMDS data (positive) input from the HDMI IN 1 connector
142 R3X2– I TMDS data (negative) input from the HDMI IN 1 connector
143 R3X2+ I TMDS data (positive) input from the HDMI IN 1 connector
144 AVCC33 - Power supply terminal (+3.3V)
