Pin No. Pin Name I/O Description
75 HSYNC O Horizontal sync signal output to the HDMI output selector and video processor
76 ODCK O Output data clock signal output to the HDMI output selector and video processor
77 to 80 Q17 to Q14 O Digital video signal output to the HDMI output selector and video processor
81, 82 Q13, Q12 O Digital video signal output to the HDMI output selector
83 to 85 Q11 to Q9 O Digital video signal output to the HDMI output selector and video processor
86 CVCC12 - Power supply terminal (+1.2V)
87 IOVCC33 - Power supply terminal (+3.3V)
88 to 94 Q8 to Q2 O Digital video signal output to the HDMI output selector and video processor
95, 96 Q1, Q0 O Digital video signal output to the HDMI output selector
97 CVCC12 - Power supply terminal (+1.2V)
98 IOVCC33 - Power supply terminal (+3.3V)
99 WS/DR0 O
Word select signal and DSD serial right channel-0 data output to the HDMI transmitter
L/R sampling clock signal output to the DSP1 and DSP2
100 SCK/DCLK O
Serial clock signal and data clock signal output to the HDMI transmitter
Bit clock signal output to the DSP1 and DSP2
101 SD0/DL0 O
Serial data and DSD serial left channel-0 data output to the HDMI transmitter
Digital audio signal (for front L/R) output to the DSP1 and DSP2
102 SD1/DR1 O
Serial data and DSD serial right channel-1 data output to the HDMI transmitter
Digital audio signal (for surround L/R) output to the DSP1
103 SD2/DL1 O
Serial data and DSD serial left channel-1 data output to the HDMI transmitter
Digital audio signal (for center, subwoofer) output to the DSP1
104 SD3/DR2 O
Serial data and DSD serial right channel-2 data output to the HDMI transmitter
Digital audio signal (for surround back L/R) output to the DSP1
105 MCLK O Audio master clock signal output to the HDMI transmitter
106 SPDIF/DL2 O
Serial data and DSD serial left channel-2 data output to the HDMI transmitter
S/PDIF audio signal output to the digital audio interface receiver and DSP1
107 GPIO3/MUTEOUT O Audio muting request signal output to the system controller, DSP1 and DSP2
108 AVCC33 - Power supply terminal (+3.3V)
109 R0XC– I TMDS clock (negative) signal input from the HDMI IN 6 connector
110 R0XC+ I TMDS clock (positive) signal input from the HDMI IN 6 connector
111 R0X0– I TMDS data (negative) input from the HDMI IN 6 connector
112 R0X0+ I TMDS data (positive) input from the HDMI IN 6 connector
113 R0X1– I TMDS data (negative) input from the HDMI IN 6 connector
114 R0X1+ I TMDS data (positive) input from the HDMI IN 6 connector
115 R0X2– I TMDS data (negative) input from the HDMI IN 6 connector
116 R0X2+ I TMDS data (positive) input from the HDMI IN 6 connector
117 AVCC12 - Power supply terminal (+1.2V)
118 R1XC– I TMDS clock (negative) signal input from the HDMI input selector
119 R1XC+ I TMDS clock (positive) signal input from the HDMI input selector
120 R1X0– I TMDS data (negative) input from the HDMI input selector
121 R1X0+ I TMDS data (positive) input from the HDMI input selector
122 R1X1– I TMDS data (negative) input from the HDMI input selector
123 R1X1+ I TMDS data (positive) input from the HDMI input selector
124 R1X2– I TMDS data (negative) input from the HDMI input selector
125 R1X2+ I TMDS data (positive) input from the HDMI input selector
126 AVCC33 - Power supply terminal (+3.3V)
127 R2XC– I TMDS clock (negative) signal input from the HDMI IN 2 connector
128 R2XC+ I TMDS clock (positive) signal input from the HDMI IN 2 connector
129 R2X0– I TMDS data (negative) input from the HDMI IN 2 connector
130 R2X0+ I TMDS data (positive) input from the HDMI IN 2 connector
131 R2X1– I TMDS data (negative) input from the HDMI IN 2 connector
132 R2X1+ I TMDS data (positive) input from the HDMI IN 2 connector
133 R2X2– I TMDS data (negative) input from the HDMI IN 2 connector
134 R2X2+ I TMDS data (positive) input from the HDMI IN 2 connector
135 AVCC12 - Power supply terminal (+1.2V)
136 R3XC– I TMDS clock (negative) signal input from the HDMI IN 1 connector
137 R3XC+ I TMDS clock (positive) signal input from the HDMI IN 1 connector
138 R3X0– I TMDS data (negative) input from the HDMI IN 1 connector
