STR-DA5500ES
144
Pin No. Pin Name I/O Description
1 RSVDNC - Not used
2 APVCC12 - Power supply terminal (+1.2V)
3 XTALVCC33 - Power supply terminal (+3.3V)
4 XTALOUT O System clock output terminal (28.322 MHz)
5 XTALIN I System clock input terminal (28.322 MHz)
6 XTALGND - Ground terminal
7 IOVCC33 - Power supply terminal (+3.3V)
8 CVCC12 - Power supply terminal (+1.2V)
9, 10 RSVDNC - Not used
11 RSVDL - Ground terminal
12 GPIO0/XCLKOUT I/O Not used
13 GPIO1/SCDT O Not used
14 GPIO2/EVNODD I/O Not used
15 RSVDNC - Not used
16, 17 GPIO4, GPIO5 I/O Not used
18 RSVDNC - Not used
19 GPIO6/DL3 O Not used
20 GPIO7/DR3 O Not used
21 RESET# I Reset signal input from the video system controller “L”: reset
22 INT O Interrupt signal output to the video system controller
23 CSCL I I2C clock signal input from the video system controller
24 CSDA I/O
Two-way I2C data bus with the HDMI transmitter, video system controller and D/A converter
(for video section)
25 CI2CA I Local I2C address selection signal input terminal Fixed at “L” in this set
26 CEC_A I/O Not used
27 CEC_D I/O Not used
28 SBVCC5 - Power supply terminal (+5V)
29 R0PWR5V I Power supply voltage (+5V) input from the HDMI IN 6 connector
30 HPD0 O Hot plug detection control signal output to the HDMI IN 6 connector
31 DSCL0 I I2C clock signal input from the HDMI IN 6 connector
32 DSDA0 I/O Two-way I2C data bus with the HDMI IN 6 connector
33 R1PWR5V I Power supply voltage (+5V) input from the HDMI IN connector
34 HPD1 O Hot plug detection control signal output to the HDMI input selector
35 DSCL1 I I2C clock signal input from the HDMI input selector
36 DSDA1 I/O Two-way I2C data bus with the HDMI input selector
37 R2PWR5V I Power supply voltage (+5V) input from the HDMI IN 2 connector
38 HPD2 O Hot plug detection control signal output to the HDMI IN 2 connector
39 DSCL2 I I2C clock signal input from the HDMI IN 2 connector
40 DSDA2 I/O Two-way I2C data bus with the HDMI IN 2 connector
41 R3PWR5V I Power supply voltage (+5V) input from the HDMI IN 1 connector
42 HPD3 O Hot plug detection control signal output to the HDMI IN 1 connector
43 DSCL3 I I2C clock signal input from the HDMI IN 1 connector
44 DSDA3 I/O Two-way I2C data bus with the HDMI IN 1 connector
45 to 49 RSVDNC - Not used
50 GND - Ground terminal
51 to 59 Q35 to Q27 O Digital video signal output to the HDMI output selector and video processor
60 CVCC12 - Power supply terminal (+1.2V)
61 IOVCC33 - Power supply terminal (+3.3V)
62 Q26 O Digital video signal output to the HDMI output selector and video processor
63, 64 Q25, Q24 O Digital video signal output to the HDMI output selector
65 to 70 Q23 to Q18 O Digital video signal output to the HDMI output selector and video processor
71 CVCC12 - Power supply terminal (+1.2V)
72 IOVCC33 - Power supply terminal (+3.3V)
73 DE O Data enable signal output to the HDMI output selector and video processor
74 VSYNC O Vertical sync signal output to the HDMI output selector and video processor
