STR-DA5500ES
143
Pin No. Pin Name I/O Description
R4 VCCO_2 - Power supply terminal (+3.3V)
R5 out_o<12> O Digital video signal output to the HDMI transmitter
R6 GND - Ground terminal
R7 - - Not used
R8 VCCO_2 - Power supply terminal (+3.3V)
R9 - - Not used
R10 GND - Ground terminal
R11 out_o<27> O Digital video signal output to the HDMI transmitter
R12 VCCO_2 - Power supply terminal (+3.3V)
R13, R14 out_o<32>, out_o<34> O Digital video signal output to the HDMI transmitter
R15 in_b<35> I Digital video signal input from the video processor
R16 SUSPEND - Not used
T1 GND - Ground terminal
T2 to T6
out_o<3>,.out_o<5>,
out_o<7>, out_o<13>,
out_o<15>
O Digital video signal output to the HDMI transmitter
T7 clk_o<0> O Output data clock signal output to the HDMI transmitter
T8 out_o<18> O Digital video signal output to the HDMI transmitter
T9 clk_o<1> O Output data clock signal output to the HDMI transmitter
T10, T11 out_o<25>, out_o<26> O Digital video signal output to the HDMI transmitter
T12 INIT_B - Not used
T13, T14 out_o<33>, out_o<35> O Digital video signal output to the HDMI transmitter
T15 DONE - Not used
T16 GND - Ground terminal
