STR-DA5500ES
142
Pin No. Pin Name I/O Description
K2 GND - Ground terminal
K3 in_a<32> I Digital video signal input from the HDMI receiver
K4 to K6 - - Not used
K7 GND - Ground terminal
K8 VCCINT - Power supply terminal (+1.2V)
K9 GND - Ground terminal
K10 VCCINT - Power supply terminal (+1.2V)
K11, K12 - - Not used
K13 non<5> - Not used
K14 in_b<23> I Digital video signal input from the video processor
K15, K16 in_b<24>, in_b<25> I Digital video signal input terminal Not used
L1 to L3
in_a<30>, in_a<33>,
in_a<34>
I Digital video signal input from the HDMI receiver
L4 to L10 - - Not used
L11 GND - Ground terminal
L12 VCCAUX - Power supply terminal (+3.3V)
L13 non<6> - Not used
L14 in_b<28> I Digital video signal input from the video processor
L15 GND - Ground terminal
L16 in_b<26> I Digital video signal input from the video processor
M1 in_a<31> I Digital video signal input from the HDMI receiver
M2 VCCO_3 - Power supply terminal (+3.3V)
M3 in_a<35> I Digital video signal input from the HDMI receiver
M4 - - Not used
M5 GND - Ground terminal
M6 VCCAUX - Power supply terminal (+3.3V)
M7, M8 - - Not used
M9 VCCO_2 - Power supply terminal (+3.3V)
M10, M11 - - Not used
M12 GND - Ground terminal
M13 non<7> - Not used
M14 to
M16
in_b<30>, in_b<29>,
in_b<27>
I Digital video signal input from the video processor
N1 de_o O Data enable signal output to the HDMI transmitter
N2 hsync_o O Horizontal sync signal output to the HDMI transmitter
N3 vsync_o O Vertical sync signal output to the HDMI transmitter
N4 out_o<8> O Digital video signal output to the HDMI transmitter
N5 - - Not used
N6 to N12
out_o<10>,.out_o<11>,
out_o<17>, out_o<20>,
out_o<21>, out_o<23>,
out_o<30>
O Digital video signal output to the HDMI transmitter
N13 - - Not used
N14 in_b<31> I Digital video signal input from the video processor
N15 VCCO_1 - Power supply terminal (+3.3V)
N16 in_b<32> I Digital video signal input from the video processor
P1, P2 out_o<0>,.out_o<1> O Digital video signal output to the HDMI transmitter
P3 GND - Ground terminal
P4 to P13
out_o<6>,.out_o<9>,
out_o<14>,.out_o<16>,
out_o<19>, out_o<24>,
out_o<22>, out_o<28>,
out_o<29>, out_o<31>
O Digital video signal output to the HDMI transmitter
P14 GND - Ground terminal
P15, P16 in_b<33>, in_b<34> I Digital video signal input from the video processor
R1 out_o<2> O Digital video signal output to the HDMI transmitter
R2 M2 - Not used
