STR-DA5500ES
141
Pin No. Pin Name I/O Description
E5 GND - Ground terminal
E6, E7 - - Not used
E8 VCCO_0 - Power supply terminal (+3.3V)
E9, E10 - - Not used
E11 VCCAUX - Power supply terminal (+3.3V)
E12 GND - Ground terminal
E13 non<0> - Not used
E14 in_b<12> I Digital video signal input terminal Not used
E15 VCCO_0 - Power supply terminal (+3.3V)
E16 in_b<11> I Digital video signal input from the video processor
F1 in_a<20> I Digital video signal input from the HDMI receiver
F2 GND - Ground terminal
F3 in_a<19> I Digital video signal input from the HDMI receiver
F4 - - Not used
F5 VCCAUX - Power supply terminal (+3.3V)
F6 GND - Ground terminal
F7 to F12 - - Not used
F13 non<1> - Not used
F14 in_b<14> I Digital video signal input from the video processor
F15 in_b<13> I Digital video signal input terminal Not used
F16 in_b<16> I Digital video signal input from the video processor
G1 to G3
in_a<21>, in_a<22>,
in_a<24>
I Digital video signal input from the HDMI receiver
G4 to G6 - - Not used
G7 VCCINT - Power supply terminal (+1.2V)
G8 GND - Ground terminal
G9 VCCINT - Power supply terminal (+1.2V)
G10 GND - Ground terminal
G11, G12 - - Not used
G13 non<2> - Not used
G14 in_b<15> I Digital video signal input terminal Not used
G15 GND - Ground terminal
G16 in_b<17> I Digital video signal input from the video processor
H1 in_a<23> I Digital video signal input from the HDMI receiver
H2 VCCO_3 - Power supply terminal (+3.3V)
H3 in_a<25> I Digital video signal input from the HDMI receiver
H4 to H7 - - Not used
H8 VCCINT - Power supply terminal (+1.2V)
H9 GND - Ground terminal
H10, H11 - - Not used
H12 VCCO_1 - Power supply terminal (+3.3V)
H13 non<3> - Not used
H14 to
H16
in_b<21>, in_b<20>,
in_b<18>
I Digital video signal input terminal Not used
J1 to J3
in_a<28>, in_a<26>,
in_a<27>
I Digital video signal input from the HDMI receiver
J4 - - Not used
J5 VCCO_3 - Power supply terminal (+3.3V)
J6, J7 - - Not used
J8 GND - Ground terminal
J9 VCCINT - Power supply terminal (+1.2V)
J10 to J12 - - Not used
J13 non<4> - Not used
J14 in_b<22> I Digital video signal input from the video processor
J15 VCCO_1 - Power supply terminal (+3.3V)
J16 in_b<19> I Digital video signal input from the video processor
K1 in_a<29> I Digital video signal input from the HDMI receiver
