STR-DA5500ES
163
Pin No. Pin Name I/O Description
M11 to
M16, M22
VSS - Ground terminal
M23 to
M25
PCI_AD18, PCI_AD19,
PCI_AD16
I/O Two-way data bus with terminal Not used
M26 PCI_C/BE2_N O
Read enable signal output to the fl ash ROM, parallel bus/I2C bus converter and parallel/se-
rial converter
N1 VCCM - Power supply terminal (+2.6V)
N2 AVREF O Reference voltage (+1.3V) output to the SD-RAM
N3 MM_WE_N O Write enable signal output to the SD-RAM
N4 MM_ADDR08 O Address signal output to the SD-RAM
N5 VDD - Power supply terminal (+1.3V)
N11 to N16 VSS - Ground terminal
N22 VCCP - Power supply terminal (+3.3V)
N23 PCI_AD17 I/O Two-way data bus with terminal Not used
N24 PCI_TRDY_N I/O Target ready signal input/output terminal Not used
N25 PCI_IRDY_N I/O Initiator ready signal input/output terminal Not used
N26 PCI_FRAME_N I/O Frame signal input/output terminal Not used
P1 MM_ADDR07 O Address signal output to the SD-RAM
P2 VSS - Ground terminal
P3 MM_ADDR01 O Address signal output to the SD-RAM
P4 MM_BA1 O Bank address signal output to the SD-RAM
P5 VDD - Power supply terminal (+1.3V)
P11 to P16 VSS - Ground terminal
P22 VCCP - Power supply terminal (+3.3V)
P23 PCI_PERR_N I/O Parity error signal input/output terminal Not used
P24 PCI_STOP_N I/O Stop signal input/output terminal Not used
P25 VSS - Ground terminal
P26 PCI_DEVSEL I/O Device selection signal input/output terminal Not used
R1, R2
MM_ADDR06,
MM_ADDR00
O Address signal output to the SD-RAM
R3 VCCM - Power supply terminal (+2.6V)
R4 MM_BA0 O Bank address signal output to the SD-RAM
R5 VCCM - Power supply terminal (+2.6V)
R11 to R16 VSS - Ground terminal
R22 VDD - Power supply terminal (+1.3V)
R23 PCI_C/BE1_N O
Write enable signal output to the fl ash ROM, parallel bus/I2C bus converter and parallel/se-
rial converter
R24 PCI_PAR I/O Parity signal input/output terminal Not used
P25 PCI_SERR_N I/O System error signal input/output terminal Not used
R26 PCI_AD15 I/O Two-way data bus with terminal Not used
T1 MM_ADDR05 O Address signal output to the SD-RAM
T2 VSS - Ground terminal
T3, T4
MM_ADDR02,
MM_ADDR10
O Address signal output to the SD-RAM
T5 VCCM - Power supply terminal (+2.6V)
T11 to T16 VSS - Ground terminal
T22 VDD - Power supply terminal (+1.3V)
T23 to T26
PCI_AD10, PCI_AD12
to PCI_AD14
I/O Two-way data bus with terminal Not used
U1 VCCM - Power supply terminal (+2.6V)
U2 MM_DQM3 O Data mask signal output to the SD-RAM (upper byte)
U3, U4
MM_ADDR04,
MM_ADDR03
O Address signal output to the SD-RAM
U5, U22 VSS - Ground terminal
U23, U24 PCI_AD08, PCI_AD09 I/O Two-way data bus with terminal Not used
U25 VSS - Ground terminal
U26 PCI_AD11 I/O Two-way data bus with terminal Not used
V1 MM_DQS3 O Data strobe signal output to the SD-RAM (upper byte)
