STR-DA5500ES
162
Pin No. Pin Name I/O Description
F23 PCI_REQ_N I Request signal input terminal Not used
F24 to F26 VDO_D28 to VDO_D26 O Digital video signal output to the D/A converter (for network (video) section)
G1 MM_DQS1 O Data strobe signal output to the SD-RAM (upper byte)
G2 VCCM - Power supply terminal (+2.6V)
G3, G4
MM_DATA09,
MM_DATA10
I/O Two-way data bus with the SD-RAM
G5 VCCM - Power supply terminal (+2.6V)
G22 VCCP - Power supply terminal (+3.3V)
G23 PCI_REQ_A_N I Request signal input terminal Not used
G24, G25 VDO_D25, VDO_D24 O Digital video signal output to the D/A converter (for network (video) section)
G26 PCI_AD30 I/O
Two-way data bus with the ash ROM, parallel bus/I2C bus converter and parallel/serial
converter
H1 VSS - Ground terminal
H2 MM_DATA07 I/O Two-way data bus with the SD-RAM
H3 VSS - Ground terminal
H4 MM_DATA08 I/O Two-way data bus with the SD-RAM
H5 VCCM - Power supply terminal (+2.6V)
H22 VCCP - Power supply terminal (+3.3V)
H23 PCI_REQ_B_N I Request signal input terminal Not used
H24 to
H26
PCI_AD31, PCI_AD28,
PCI_AD27
I/O
Two-way data bus with the ash ROM, parallel bus/I2C bus converter and parallel/serial
converter
J1 MM_DQS0 O Data strobe signal output to the SD-RAM (lower byte)
J2 MM_CKE O Clock enable signal output to the SD-RAM
J3 VCCM - Power supply terminal (+2.6V)
J4 MM_DQM1 O Data mask signal output to the SD-RAM (upper byte)
J5 VSS - Ground terminal
J22 VDD - Power supply terminal (+1.3V)
J23 PCI_AD29 I/O
Two-way data bus with the ash ROM, parallel bus/I2C bus converter and parallel/serial
converter
J24 VCCP - Power supply terminal (+3.3V)
J25, J26 PCI_AD25, PCI_AD24 I/O
Two-way data bus with the ash ROM, parallel bus/I2C bus converter and parallel/serial
converter
K1 VCCM - Power supply terminal (+3.3V)
K2 MM_DQM0 O Data mask signal output to the SD-RAM (lower byte)
K3, K4
MM_ADDR11,
MM_ADDR12
O Address signal output to the SD-RAM
K5 VSS - Ground terminal
K22 VDD - Power supply terminal (+1.3V)
K23 PCI_AD26 I/O
Two-way data bus with the ash ROM, parallel bus/I2C bus converter and parallel/serial
converter
K24 PCI_C/BE3_N I/O Command and byte enable signal input/output terminal Not used
K25 VSS - Ground terminal
K26 PCI_IDSEL I ID selection signal input terminal Not used
L1 MM_RAS_N O Row address strobe signal output to the SD-RAM
L2 VCCM - Power supply terminal (+2.6V)
L3 MM_CS0_N O Chip select signal output to the SD-RAM
L4 MM_ADDR09 O Address signal output to the SD-RAM
L5 VCCM - Power supply terminal (+3.3V)
L11 to L16,
L22
VSS - Ground terminal
L23 to L26
PCI_AD23 to
PCI_AD20
I/O Two-way data bus with terminal Not used
M1 MM_CLK O Clock signal (positive) output to the SD-RAM
M2 MM_CLK_N O Clock signal (negative) output to the SD-RAM
M3 VSS - Ground terminal
M4 MM_CAS_N O Column address strobe signal output to the SD-RAM
M5 VCCM - Power supply terminal (+2.6V)
