STR-DA5500ES
165
Pin No. Pin Name I/O Description
AC3 MM_DATA17 I/O Two-way data bus with the SD-RAM
AC4 VCCM - Power supply terminal (+2.6V)
AC5 VDI_D33 I Not used
AC6 VDI_CLK2 I/O Not used
AC7 to
AC14
VDI_D07, VDI_D10,
VDI_D14, VDI_D16,
VDI_D17, VDI_D22,
VDI_D27, VDI_D31
I Not used
AC15 LAN_TXD1 O Digital data output to the ethernet interface
AC16 GPIO12 I/O Not used
AC17 AI_SD2 I Serial data input terminal Not used
AC18 BOOT_MODE07 I Interrupt signal input from the parallel/serial converter
AC19 XIO_D10 I/O Two-way data bus with terminal Not used
AC20 XIO_ACK I Ready/busy selection signal input from the fl ash ROM
AC21 GPIO25 I/O Not used
AC22 XIO_D08 I/O Two-way data bus with terminal Not used
AC23 XIO_SEL3 O Chip select signal output to the parallel bus/I2C bus converter
AC24 LAN_CRS I Carrier sense input from the ethernet interface
AC25 LAN_MDC O Management data clock signal output to the ethernet interface
AC26 LAN_MDIO I/O Two-way management data bus with the ethernet interface
AD1 to
AD3
MM_DATA30, MM_
DATA31, MM_DATA16
I/O Two-way data bus with the SD-RAM
AD4 VSS - Ground terminal
AD5 to
AD11
VDI_D04 to VDI_D06,
VDI_D12, VDI_D18,
VDI_D21, VDI_D26
I Not used
AD12 VCCP - Power supply terminal (+3.3V)
AD13 LAN_TX_EN O Enable signal output to the ethernet interface
AD14 LAN_TXD2 O Digital data output to the ethernet interface
AD15 LAN_RX_ER I Error signal input from the ethernet interface
AD16,
AD17
LAN_RXD2,
LAN_RXD3
I Digital audio/video signal input from the ethernet interface
AD18 VCCP - Power supply terminal (+3.3V)
AD19 AO_OSCLK O Serial data transfer clock signal output to the D/A converter (for network (audio) section)
AD20 AI_SCK I Bit clock signal input terminal Not used
AD21 AI_WS I L/R sampling clock signal input terminal Not used
AD22 AI_SD3 I Serial data input terminal Not used
AD23 BOOT_MODE06 I AC cut detection signal input terminal “H”: AC cut
AD24 VCCP - Power supply terminal (+3.3V)
AD25 XIO_D13 I/O Two-way data bus with terminal Not used
AD26 XIO_SEL2 O Chip select signal output to the parallel/serial converter
AE1 VDI_V2 I Not used
AE2 to
AE5
VDI_D32, VDI_D02,
VDI_D00, VDI_D09
- Not used
AE6 VCCP - Power supply terminal (+3.3V)
AE7 to
AF10
VDI_D15, VDI_D11,
VDI_D20, VDI_D24
- Not used
AE11 VSS - Ground terminal
AE12 VDI_D29 - Not used
AE13 LAN_TX_ER O Error signal output to the ethernet interface
AE14 LAN_TXD0 O Digital data output to the ethernet interface
AE15 LAN_RX_DV I Data valid signal input from the ethernet interface
AE16 LAN_RXD0 I Digital audio/video signal input from the ethernet interface
AE17 VSS - Ground terminal
AE18 AO_SCK O Bit clock signal output to the D/A converter (for network (audio) section)
AE19 AO_SD1 O Serial data output terminal Not used
AE20 AO_WS O L/R sampling clock signal output to the D/A converter (for network (audio) section)
