STR-DA5500ES
166
Pin No. Pin Name I/O Description
AE21,
AE22
GPIO13, GPIO14 I/O Not used
AE23 AI_SD0 I Serial data input terminal Not used
AE24 GPIO7 I/O Not used
AE25 VSS - Ground terminal
AE26 XIO_D09 I/O Two-way data bus with terminal Not used
AF1 VSS - Ground terminal
AF2 VCCP - Power supply terminal (+3.3V)
AF3 to AF6
VDI_D01, VDI_D03,
VDI_D08, VDI_D13
I Not used
AF7 VDI_CLK1 I/O Not used
AF8 to
AF12
VDI_D19, VDI_D23,
VDI_D25, VDI_D28,
VDI_D30
I Not used
AF13 VDI_V1 I Not used
AF14 LAN_TX_CLK I Serial data transfer clock signal output to the ethernet interface
AF15 LAN_TXD3 O Digital data output to the ethernet interface
AF16 LAN_RX_CLK I Serial data transfer clock signal input from the ethernet interface
AF17 LAN_RXD1 I Digital audio/video signal output to the ethernet interface
AF18 LAN_CLK O System clock signal output to the ethernet interface
AF19 AO_SD0 O Digital audio signal output to the D/A converter (for network (audio) section)
AF20,
AF21
AO_SD2, AO_SD3 O Serial data output terminal Not used
AF22 SPDO O S/PDIF signal output terminal Not used
AF23 AI_OSCLK I Serial data transfer clock signal input terminal Not used
AF24 AI_SD1 I Serial data input terminal Not used
AF25,
AF26
BOOT_MODE04/
WDOG_OUT,
BOOT_MODE05
- Not used
