STR-DA5500ES
19
Items Display Remark
Video calibration
(Video factory menu)
V.CALIBRATION START? Procedure:
1. “DVD” is selected by using [INPUT SELECTOR] dial.
2. Connect a color pattern generator to the COMPONENT
VIDEO ASSIGNABLE (INPUT ONLY) IN2 jack (J6007) on
the A-VIDEO board and DVD VIDEO IN jack (J6003) on the
A-VIDEO board.
3. Input 100% color bars signal from the color pattern generator.
4. Menu that measures individual difference of hardness by
automatic operation in pressing the jog switch, and corrects
reference value. In a measurement once, only one of NTSC/
PAL/HD can be measured, repeat NTSC/PAL/HD calibration
from procedure 4.
“Check XXXX V-IN” at display:
Video signal necessary for the measurement while measuring
it last time was not detected and it became an error
Confi rm the input of the video of the terminal connection etc.,
and measure the jog switch again pressing
DDR access check DDR CHECK [XX] sec XX: Time to do access check on DDR (for design evaluation)
(Video factory menu)
Auto cal mic test SPEAKER OUT [XXXXX] XXXXX: Selection of speaker output audio [SOURCE]: normal-
ly mode, [MIC]: mode that output audio from mic from speaker
FL display fonts test
FL FONT [0x ∗∗ = X] ∗∗: 20 to FE, X: character
FL display test (all on) Each time [DISPLAY] button to change as follows all on t
test pattern 1 t test pattern 2 t all off t all on
Super reset SUPER RESET [XXX] Not used for the servicing
If super reset is performed, “up convert signal level adjustment”
will also be initialized
When EEPROM initialization is required, perform the “memory
clearing mode”
RAM capacity register/
Error factor register
RAM WATCH MENU Not used for the servicing
EERROM debug
EEPROM [∗∗∗∗] [XX]
Not used for the servicing
Protector on/off PROTECTOR ON/OFF [XXX] Not used for the servicing
Audio swap SWAP [XXXXXXXXXXX] Not used for the servicing
Volume value display (FL/FR)
FL∗∗∗∗ FR XXXX
Not used for the servicing
Volume value display (SL/SR)
SL∗∗∗∗ SR XXXX
Not used for the servicing
Volume value display (CT/SW)
CT∗∗∗∗ SW XXXX
Not used for the servicing
Volume value display (SBL/SBR)
SBL∗∗∗∗ SBR XXXX
Not used for the servicing
DAC mute fl ag upper DAC MUTE U XXXXXXXX Not used for the servicing
DAC mute fl ag lower DAC MUTE L XXXXXXXX Not used for the servicing
2nd volume value display 2nd VOLUME XXX Not used for the servicing
Dark out duty DARK OUT DUTY [XXX%] Not used for the servicing
CORTEZ read CORTEZ READ [XXX] Not used for the servicing
Check H.A.T.S. playback
component
CHK HATS COMP [XXX] Not used for the servicing
H.A.T.S. mode fi x HATS FIX [XXXXXXX] Not used for the servicing
H.A.T.S. rate control HATS RATE [XXXXXX] Not used for the servicing
H.A.T.S. error process HATS ERR PROC [XXX] Not used for the servicing
H.A.T.S. error trig HATS ERR TRIG Not used for the servicing
Pass through auto debug PASS THRU AUTO DBG Not used for the servicing
