Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
STR-DA5500ES
228
< CONNECTOR >
* CN1701 1-573-828-11 CONNECTOR, BOARD TO BOARD 14P
CN1704 1-573-846-11 CONNECTOR, BOARD TO BOARD 14P
CN1761 1-564-720-11 PIN, CONNECTOR (SMALL TYPE) 4P
< DIODE >
D1721 8-719-991-33 DIODE 1SS133T-77
D1722 8-719-991-33 DIODE 1SS133T-77
D1771 8-719-991-33 DIODE 1SS133T-77
D1772 8-719-991-33 DIODE 1SS133T-77
< TRANSISTOR >
Q1722 8-729-042-09 TRANSISTOR 2SA1038S-RSE-TP
Q1723 8-729-042-09 TRANSISTOR 2SA1038S-RSE-TP
Q1724 8-729-119-78 TRANSISTOR 2SC2785-HFE
Q1772 8-729-042-09 TRANSISTOR 2SA1038S-RSE-TP
Q1773 8-729-042-09 TRANSISTOR 2SA1038S-RSE-TP
Q1774 8-729-119-78 TRANSISTOR 2SC2785-HFE
< RESISTOR >
R1725 1-216-065-91 METAL CHIP 4.7K 5% 1/10W
0 R1726 1-240-855-91 CARBON 6.2K 5% 1/4W F
R1727 1-216-055-00 METAL CHIP 1.8K 5% 1/10W
R1728 1-216-077-91 METAL CHIP 15K 5% 1/10W
R1729 1-216-080-00 METAL CHIP 20K 5% 1/10W
R1730 1-216-053-00 METAL CHIP 1.5K 5% 1/10W
R1731 1-216-089-91 METAL CHIP 47K 5% 1/10W
R1732 1-216-077-91 METAL CHIP 15K 5% 1/10W
R1733 1-247-871-91 CARBON 47K 5% 1/4W
R1734 1-216-081-00 METAL CHIP 22K 5% 1/10W
R1735 1-249-439-11 CARBON 68K 5% 1/4W
R1736 1-216-105-91 METAL CHIP 220K 5% 1/10W
R1775 1-216-065-91 METAL CHIP 4.7K 5% 1/10W
0 R1776 1-240-855-91 CARBON 6.2K 5% 1/4W F
R1777 1-216-055-00 METAL CHIP 1.8K 5% 1/10W
R1778 1-216-077-91 METAL CHIP 15K 5% 1/10W
R1779 1-216-080-00 METAL CHIP 20K 5% 1/10W
R1780 1-216-053-00 METAL CHIP 1.5K 5% 1/10W
R1781 1-216-089-91 METAL CHIP 47K 5% 1/10W
R1782 1-216-077-91 METAL CHIP 15K 5% 1/10W
R1783 1-247-871-91 CARBON 47K 5% 1/4W
R1784 1-216-081-00 METAL CHIP 22K 5% 1/10W
R1785 1-249-439-11 CARBON 68K 5% 1/4W
R1786 1-216-105-91 METAL CHIP 220K 5% 1/10W
************************************************************
SPSW BOARD
***********
< DIODE >
D251 6-501-817-01 DIODE MA2J1110GLS0
D252 6-501-817-01 DIODE MA2J1110GLS0
< RESISTOR >
R251 1-216-025-11 METAL CHIP 100 5% 1/10W
R252 1-216-025-11 METAL CHIP 100 5% 1/10W
R253 1-216-089-91 METAL CHIP 47K 5% 1/10W
R254 1-216-089-91 METAL CHIP 47K 5% 1/10W
< SWITCH >
S251 1-762-684-11 SWITCH, ROTARY (SPEAKERS)
************************************************************
SPTM BOARD
***********
< CAPACITOR >
C4101 1-137-395-91 MYLAR 0.022uF 5% 100V
C4102 1-137-395-91 MYLAR 0.022uF 5% 100V
C4103 1-137-395-91 MYLAR 0.022uF 5% 100V
C4104 1-137-395-91 MYLAR 0.022uF 5% 100V
C4105 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C4106 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C4107 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C4108 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C4109 1-115-339-11 CERAMIC CHIP 0.1uF 10% 50V
C4110 1-115-339-11 CERAMIC CHIP 0.1uF 10% 50V
< CONNECTOR >
CX4101 1-785-105-11 PIN, CONNECTOR (3.96mm PITCH) 7P
CX4102 1-785-104-11 PIN, CONNECTOR (3.96mm PITCH) 6P
CX4103 1-784-921-11 PIN, CONNECTOR 4P
< DIODE >
D4101 6-501-817-01 DIODE MA2J1110GLS0
D4102 6-501-817-01 DIODE MA2J1110GLS0
< TRANSISTOR >
Q4101 8-729-230-49 TRANSISTOR 2SC2712-YG
Q4102 8-729-230-49 TRANSISTOR 2SC2712-YG
< RESISTOR >
R4101 1-208-445-41 RES-CHIP 2.2K 2% 1/10W
R4102 1-208-445-41 RES-CHIP 2.2K 2% 1/10W
0 R4103 1-249-393-91 CARBON 10 5% 1/4W F
R4104 1-208-462-41 RES-CHIP 10K 2% 1/10W
0 R4105 1-249-393-91 CARBON 10 5% 1/4W F
R4106 1-208-462-41 RES-CHIP 10K 2% 1/10W
0 R4107 1-249-393-91 CARBON 10 5% 1/4W F
0 R4108 1-249-393-91 CARBON 10 5% 1/4W F
0 R4109 1-249-393-91 CARBON 10 5% 1/4W F
0 R4110 1-249-393-91 CARBON 10 5% 1/4W F
< RELAY >
RY4101 1-515-920-11 RELAY (24V)
RY4102 1-515-920-11 RELAY (24V)
< TERMINAL >
0 TM4101 1-780-404-11 TERMINAL BOARD (SP) (8P)
(SPEAKERS SURROUND/SUR BACK (ZONE2))
************************************************************
TEMPERATURE DETECTION BOARD
*****************************
< CAPACITOR >
C1909 1-114-714-41 CERAMIC 0.1uF 10% 50V
C1910 1-114-714-41 CERAMIC 0.1uF 10% 50V
C1913 1-114-714-41 CERAMIC 0.1uF 10% 50V
