Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
STR-DA5500ES
229229
< DIODE >
D1906 8-719-109-93 DIODE RD6.2ESB2
< IC >
0 IC1903 6-710-072-01 IC LM61CIZ/LFT2
0 IC1905 6-710-072-01 IC LM61CIZ/LFT2
< RESISTOR >
R1928 1-249-414-11 CARBON 560 5% 1/4W
************************************************************
VIDEO2 BOARD
************
< CAPACITOR >
C261 1-104-665-11 ELECT 100uF 20% 25V
C262 1-104-665-11 ELECT 100uF 20% 25V
C263 1-115-416-11 CERAMIC CHIP 0.001uF 5% 25V
C264 1-115-416-11 CERAMIC CHIP 0.001uF 5% 25V
C265 1-100-597-91 CERAMIC CHIP 0.1uF 10% 25V
C266 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C267 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C268 1-100-597-91 CERAMIC CHIP 0.1uF 10% 25V
C269 1-164-733-11 CERAMIC CHIP 820PF 10% 50V
C270 1-164-733-11 CERAMIC CHIP 820PF 10% 50V
C271 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C272 1-162-957-11 CERAMIC CHIP 220PF 5% 50V
C273 1-162-957-11 CERAMIC CHIP 220PF 5% 50V
< CONNECTOR >
CN261 1-784-923-11 PIN, CONNECTOR 7P
CN263 1-779-978-11 PIN, CONNECTOR 3P
CN264 1-784-922-11 PIN, CONNECTOR 5P
CN265 1-564-705-11 PIN, CONNECTOR (SMALL TYPE) 3P
< DIODE >
D261 6-501-817-01 DIODE MA2J1110GLS0
D262 6-501-817-01 DIODE MA2J1110GLS0
D263 6-501-817-01 DIODE MA2J1110GLS0
D264 6-501-817-01 DIODE MA2J1110GLS0
< EARTH TERMINAL >
* ET261 1-537-738-21 TERMINAL, EARTH
* ET262 1-537-738-21 TERMINAL, EARTH
< IC >
IC261 8-759-710-97 IC NJM4565M-D
IC262 6-600-219-01 IC GP1FM313RZ0F (VIDEO 2 IN DIGITAL (OPT))
< JACK >
J261 1-815-313-11 JACK (PHONES)
J262 1-770-571-1
1 JACK BLOCK, PIN (L TYPE) 3P
(VIDEO 2 IN AUDIO/VIDEO)
< RESISTOR >
R261 1-216-809-11 METAL CHIP 100 5% 1/10W
R262 1-216-821-11 METAL CHIP 1K 5% 1/10W
R263 1-216-821-11 METAL CHIP 1K 5% 1/10W
R264 1-211-990-11 METAL CHIP 75 0.5% 1/10W
R265 1-216-841-11 METAL CHIP 47K 5% 1/10W
VIDEO2
R266 1-216-841-11 METAL CHIP 47K 5% 1/10W
R267 1-216-864-11 SHORT CHIP 0
R268 1-216-864-11 SHORT CHIP 0
R269 1-216-864-11 SHORT CHIP 0
R270 1-216-864-11 SHORT CHIP 0
R273 1-216-864-11 SHORT CHIP 0
************************************************************
MISCELLANEOUS
**************
3 1-500-082-11 CLAMP, SLEEVE FERRITE (US, CND)
7 1-500-386-11 FILTER, CLAMP (FERRITE CORE)
8 1-543-798-11 FILTER, CLAMP (FERRITE CORE) (AEP, UK)
52 1-693-728-31 TUNER (FM/AM) (US, CND)
52 1-693-737-21 TUNER (FM/AM) (AEP, UK)
53 1-500-082-11 CLAMP, SLEEVE FERRITE (US, CND)
53 1-500-386-11 FILTER, CLAMP (FERRITE CORE) (AEP, UK)
55 1-828-327-51 WIRE (FLAT TYPE) (13 CORE)
101 1-500-082-11 CLAMP, SLEEVE FERRITE (US, CND)
152 1-500-386-11 FILTER, CLAMP (FERRITE CORE)
204 1-823-669-51 WIRE (FLAT TYPE) (11 CORE) (AEP, UK)
204 1-828-956-51 WIRE (FLAT TYPE) (9 CORE) (US, CND)
207 1-543-793-11 FILTER, CLAMP (FERRITE CORE) (US, CND)
208 1-543-798-11 FILTER, CLAMP (FERRITE CORE)
209 1-500-386-11 FILTER, CLAMP (FERRITE CORE) (US, CND)
262 1-543-793-11 FILTER, CLAMP (FERRITE CORE) (AEP, UK)
263 1-966-745-11 HARNESS (With white line mark)
264 1-966-746-11 HARNESS
0 405 1-821-082-21 INLET, AC 2P (
-
AC IN)
0 F001 1-532-504-33 FUSE (T4AL/250V) (AEP, UK)
0 F001 1-533-311-12 FUSE, GLASS CYLINDRICAL (DIA.5) (8A/125V)
(US, CND)
0 F03 1-533-420-11 FUSE, GLASS CYLINDRICAL (DIA.5) (5A/125V)
(US, CND)
0 F1403 1-532-504-33 FUSE (T4AL/250V)
0 F1404 1-532-504-33 FUSE (T4AL/250V)
0 F1405 1-532-506-33 FUSE (T6.3AL/250V)
Q1507 8-729-051-92 TRANSISTOR 2SD2560
Q1508 8-729-051-93 TRANSISTOR 2SB1647
Q1521 8-729-026-08 TRANSISTOR 2SC4495
Q1557 8-729-051-92 TRANSISTOR 2SD2560
Q1558 8-729-051-93 TRANSISTOR 2SB1647
Q1571 8-729-026-08 TRANSISTOR 2SC4495
Q1607 8-729-051-92 TRANSISTOR 2SD2560
Q1608 8-729-051-93 TRANSISTOR 2SB1647
Q1621 8-729-026-08 TRANSISTOR 2SC4495
Q1707 8-729-051-92 TRANSISTOR 2SD2560
Q1708 8-729-051-93 TRANSISTOR 2SB1647
Q1721 8-729-026-08 TRANSISTOR 2SC4495
Q1757 8-729-051-92 TRANSISTOR 2SD2560
Q1758 8-729-051-93 TRANSISTOR 2SB1647
Q1771 8-729-026-08 TRANSISTOR 2SC4495
Q1807 8-729-051-92 TRANSISTOR 2SD2560
Q1808 8-729-051-93 TRANSISTOR 2SB1647
Q1821 8-729-026-08 TRANSISTOR 2SC4495
Q1857 8-729-051-92 TRANSISTOR 2SD2560
Q1858 8-729-051-93 TRANSISTOR 2SB1647
Q1871 8-729-026-08 TRANSISTOR 2SC4495
0 T1 1-445-239-11 TRANSFORMER, POWER (AEP, UK)
