STR-DA5500ES
5
ATTENTION OF MIS-CONNECTOR INSERTION
POWER AMP BLOCK SERVICE POSITION
• Please connect following extension jig.
Jig No. Part No. Pitch (mm) Cores Length (mm)
1
J-2501-291-A 2 12 300
2
J-2501-311-A 2 15 300
A-CLASS AMP board
(CN1504)
Connect extension jig 2 to the
A-CLASS AMP board (CN1505)
and E-VOL board (CN1202).
E-VOL boar
(CN1206)
A-CLASS AMP board
(CN1505)
power AMP Block
Connect extension jig 1 to the
A-CLASS AMP board (CN1504)
and E-VOL board (CN1201).
E-VOL board
(CN1201)
insulating sheet
F-HDMI-SATA board
white line mark
white silk print
D-VIDEO board
The connector that there is a white line mark in the harness
It connects it with the connector from which white silk is printed on the substrate.
white line mark
white silk print
