DPU/DO - Page 15 - REV. 5/25/00
Diagnose Board Inputs
--------------------------------
Unit Number -------------- 1
-- Select a Function...
<1> Diagnose Board Inputs
<2> View/Set Parameters
<3> Examine Hex Registers
<NEXT> <LAST> <ESCAPE>
--------------------------------
-- Diagnostic Selection Screen --
From this screen, the user is presented with the three main functions of the System Diagnostic
Unit. These functions can be performed on any of the controllers, whether they are carriage
controllers or safety floor monitors. Using the NEXT and LAST keys allows the user to change
between the controllers with the addressed controller's unit number appearing in the upper right
corner of the display. By pressing a 1 (Diagnose Board Inputs) on the keypad, all Power
Pro/EC300/EC400 circuit inputs, such as limit switches and sweeps, can be observed remotely.
The next five screens show what can be expected in this mode. The second (View/Set
Parameters) and third (Examine Hex Registers) functions are described in detail on page 23.
