DPU/DO - Page 40 - REV. 5/25/00
--------------------------------
**Set Parameters For Unit - 1 **
--> OPTION VALUE 3 -Last Spacing
Enter Value <1-255> - 6_
Use < > to Select Option
Value <ENTER> to Set Option
<SAVE> to Save <ESCAPE> to Exit
--------------------------------
-- Option Value 3 Last Spacing Parameter Screen --
This parameter relates to the travel time of the last carriage when the system is evenly spacing.
The travel time of the last carriage needs to be reduced to allow for the entire module to coast to
a stop. This parameter is an amount of time, expressed in tenths of seconds, which is subtracted
from the aisle spacing parameter set in option value 1. This helps make the “last” aisle spacing
consistent with the others. See page 23 for details regarding entry of a numeric value.
--------------------------------
**Set Parameters For Unit - 1 **
---> OPTION REGISTER 3-AUTO MOVE
(0)Off (2)Auto (4)LS
(1)Rove (3)AS (5)RS
Use < > to Select Option
Use <NUMBER> to Set Option
<SAVE> to Save <ESCAPE> to Exit
--------------------------------
-- Option Register 3 Auto Move Parameter Screen --
This option register determines the function of the system when Jumper J22 Option 3 is closed
on the carriage controller. Note that "Even Spacing" is not supported by software versions prior
to 4.7. The functions are listed below. If this screen is not set for "Auto Aisle" then the
following "Aisle Number" screen will not be displayed. Hardware Jumper J22 Option 3 (on one
controller) has to be installed for the selected feature to work. It is recommended to use only one
controller to make it easier if the feature needs to be removed. The Auto Move timer is active
only when the module is in the “Ready For Use” state.
0 - Option Jumper Disabled - nothing happens when the hardware jumper is closed.
1 - Roving Aisle - Module accesses a different aisle after a set time period.
2 - Auto Aisle - Module accesses a specific aisle after a set time period.
3 - * Alternate Closing then Evenly Spaces Module after set time period (rev 4.7 and later).
4 - * Close left then Evenly Spaces Module after set time period (EC400 controllers only).
5 - * Close right then Evenly Spaces Module after set time period (EC400 controllers only).
* Note: To invoke any of the evenly spacing auto move functions, you have to calculate and set
option value 1 (previous page), option value 3 (top of this page) and option value 4 (next page).
To Next Page
