DPU/DO - Page 38 - REV. 5/25/00
--------------------------------
**Set Parameters For Unit - 1 **
--->OPTION REGISTER 1-NIGHT PARK
(0)Off (2)RS (4)LC (6)AC
(1)LS *(3)AS (5)RC
Use < > to Select Option
Use <NUMBER> to Set Option
<SAVE> to Save <ESCAPE> to Exit
--------------------------------
-- Option Register 1 Night Park Parameter Screen --
This determines the function of the module when jumper J23 option 1 is closed on the carriage controller
(usually generated by the building management system normally closed contacts, interfaced to only one
controller per module - see drawing 480268.001). Locked aisles are reset and safeties remain active.
0 - Option Jumper Disabled - nothing happens when the hardware jumper is closed.
1 - Module closes to the left, evenly spaces carriages, deactivates controls, remains parked.
2 - Module closes to the right, evenly spaces carriages, deactivates controls, remains parked.
3 - Alternates direction closing, evenly spaces carriages, deactivates controls, remains parked.
4 - Module closes to the left, deactivates control heads, remains parked.
5 - Module closes to the right, deactivates control heads, remains parked.
6 - Module alternates direction closing, deactivates control heads, remains parked.
--------------------------------
**Set Parameters For Unit - 1 **
--->OPTION REGISTER 2-FIRE PARK
(0)Off *(2)RS (4)LC
(1)LS (3)AS (5)RC
Use < > to Select Option
Use <NUMBER> to Set Option
<SAVE> to Save <ESCAPE> to Exit
--------------------------------
-- Option Register 2 Fire Park Parameter Screen --
This determines the function of the module when jumper J23 option 2 is closed on the carriage controller
(usually by the building management system normally closed contacts, interfaced to only one controller
per module - see drawing 480268.001). Locked aisles are reset and safeties remain active. Note: EC400
control heads remain functional to allow fire fighting personnel access after parking.
0 - Option Jumper Disabled - nothing happens when the hardware jumper is closed.
1 - Module closes left, evenly spaces carriages, deactivates heads.
2 - Module closes right, evenly spaces carriages, deactivates heads.
3 - Module alternate direction closing, evenly spaces carriages, deactivates heads.
4 - Module closes to the left, deactivates heads.
5 - Module closes to the right, deactivates heads.
On version 4.7 & later; stationary carriages are made moveable for both Night and Fire Park modes.
