DPU/DO - Page 7 - REV. 5/25/00
Power Pro/EC300/EC400 System Diagnostic
Overview and Requirements
The Power Pro/EC300/EC400 System Diagnostic consists of a single unit and interconnecting
cable, which connects to any Spacesaver module of mobile storage, fitted with the Power Pro,
EC300 or EC400 controls. The System Diagnostic Unit is housed in a black plastic case and
comes equipped with system communication cable, wall-mounted transformer power supply and
12 VDC auto adapter
1
. The Diagnostic Unit provides the following functions:
Automated troubleshooting of Power Pro, EC300 and EC400 system communication.
Diagnostic testing of Power Pro, EC300 and EC400 board functions such as limit switch and
safety sweep inputs.
Setting of system parameters on the Power Pro, EC300A and EC400 series of control boards.
Remote operation of a Power Pro, EC300 or EC400 module of mobile storage.
All functions are available on the System Diagnostic Unit without changing setups or operational
modes.
Requirements for Use
Connection to Spacesaver Power Pro, EC300 or EC400 Series Mobile Storage Controls with
provided communication cable. The Power Pro requires a ten-pin connector adapter.
One 120-Volt Power Supply
2
located within 5 feet of the unit. The unit will operate without
outlet power if fully charged. See page 10 for charging instructions.
1
&
2
As of October 1998, Spacesaver has changed the diagnostic unit to get its power from the
logic board eliminating the need for internal batteries, the charger unit and power jack.
