SpeakerCraft MODE 3.1 User Manual

49
SPECIFICATIONS
MODE 3.1 Keypad
3.5” High Resolution Display With 64K Color (16 bit)
Unique Scroll Wheel For easy Menu Navigation
Volume Control Knob With Back Lit Level Indicators
8 Back Lit Hard Key Confi guration Buttons
Built in IR Receiver
Requires MZC Controller
Fits most standard dual gang boxes
Dimensions: 2 5/8”H x 3 5/8”W x 1 5/8”D (67mm x 92mm x 41mm)
MODE Free Keypad
Robust 2.4GHz Wireless Connection
Built-in Antenna With Up To 100 ft Range
Rechargeable Li-ion Battery Provides up to 2 Weeks of Operation Between Charges
Provides a 2-way metadata/control link with MZC System through the MODE Free Coordinator
2 Docking Options (MODE Free Wall Dock, MODE Free Table Dock)
Dimensions: 2 5/8”H x 3 5/8”W x 1 1/2”D (67mm x 92mm x 38mm)
MODE Free Coordinator
Robust 2.4GHz Wireless Connection
External 3 1/2” Antenna With Up To 100 ft Range
Provides a 2-way metadata/control link with MZC System and MODE Free Keypad
Supports up to 16 MODE Free Keypads
Powered over CAT5 cable from the MZC System
Auxiliary power jack
Power, activity, network join and reset status indicators
Dimensions: 7/8”H x 2 1/2”W x 3 3/4”D (22mm x 64mm x 95mm)
MODE Adapter
RJ45 jack for connection to MODE Base
RJ45 jack for connection to the MZC-64/66/88
Quick[Lock system for stacking multiple Base Adapters
One PS-3 Power Supply supports up to 6 Adapters and 6 MODE Bases
PS-3 Power Supply not included
Dimensions: 1 1/4”H x 5 3/8”W x 3”D (32mm x 137mm x 76mm)
MODE Base
Interface between an Apple iPod and MZC-64/66/88
Converts iPod audio into a balanced audio signal
Converts iPod serial data to RS485 data
RJ45 jack for CAT5 connection to MODE Base Adapter
USB port for syncing iPod to computer for fi le updating
Includes various iPod sized adapters
Dimensions: 1 7/16”H x 3 1/4”W x 3 1/4”D (37mm x 83mm x 83mm)
MODE Free Wall Dock
Provides a hard wired connection for MODE Free Keypad
Closeable door when MODE Free is undocked
6 hour standard charge
Charge indicator
Powered over CAT5 cable from MZC System
Dimensions: 5”H x 5 15/32”W x 2 15/32”D (127mm x 139mm x 63mm)
MODE Free Table Dock
Provides a convenient, elegant charging dock for the MODE Free Keypad
Positions the MODE Free Keypad at an angle for easy operation when docked
2 hour quick charge
Charge indicator
Includes 12V DC power supply
Dimensions: 3”H x 4 3/4”W x 4 3/16”D (76mm x 121mm x 106mm)
