SC5 Signal Conversion Specifications
41
Analog outputs specifications
Connectors 8 × BNC
Coupling DC, referenced to AGND
Output voltage range ±10 V into 1 kΩ or larger (0 to 10 Vper internal jumper per
channel)
Output impedance < 1 Ω, short circuit safe
Analog bandwidth DC - 40 kHz (-3 dB)
Analog filter type 5
th
order Butterworth
DA converter 20-bit, monotonic, 1 MS/s
Effective resolution 20-bit, 22-bit with patented hrDAC™ technology with
active glitch compensation.
DNL ± 0.5 LSB (bipolar) typical, ± 0.75 LSB (unipolar) typical
@ 20 bit
INL ± 2 LSB typical @ 20 bit
Output noise density < 23 nV/sqrt(Hz) @ 100 Hz, ±10 V output range
RMS noise 0.1 – 10 Hz < 180 nV rms, ±10 V output range
Peak-peak noise 0.1 – 10 Hz < 1.1 µVp-p, ±10 V output range
RMS noise 10 Hz – 300 kHz < 10 µV rms, ±10 V output range
Peak-peak noise 10 Hz – 300 kHz < 85 µVp-p, ±10 V output range
Temperature coefficient < 3 µV/K @ 0 V output, <75 µV/K @ 9.9 V output
SINAD >96 dB @ 100 Hz, 9 V
THD+N >115 dB @ 100 Hz, 9 V (FFT bandwidth 1 kHz)
Maximum output current ±20 mA
Maximum slew rate 2.5 V/µs into 10 kΩ
Offset < 550 µV uncalibrated, < 25 µV calibrated
EMC protection According to EN61326-1, Table-1
