36 SPEKTRUM NX7e • TRANSMITTER INSTRUCTION MANUAL
EN
My List Setup
My List gives you quick access to a short list of commonly used
menu items you create.
• Press the Function button to open My List
• Scroll to select the menu you want, and click to choose that option
• CLEAR will take you to the first entry on the list
• BACK or FUNC will exit to original screen
IMPORTANT: If a menu option is not available on the Function
List such as due to a Wing/Tail type change, it will not be
selectable from the My List.
IMPORTANT: You can pick entries from the Function List,
however you cannot pick sub-options for the My List setup.
For compatible video transmitters, this menu can select the options
directly from your NX7e. Set the power level and frequency of your
video transmitter, and select SEND to make the change.
VTX Setup
Function Bar
Ticker Tape Setup
The screen can display up to 10 features on the bar.
Each slot can be configured to hold:
• A telemetry sensor report
• The position of an input switch
Sensor Configuration
Pick the sensors you want to display from the list of sensors in the
active telemetry list. After selecting a sensor, configure the data to
display to suit your needs.
Field
Select the input you want to have displayed, and the amount of
time it should be shown.
The Function Bar on the NX7e offers 2 features, a Ticker Tape to
show telemetry values and My List which allows quick access to
menu items chosen that are frequently used.
When the NX7e transmitter is showing the normal display (home
screen), the system shows the telemetry scrolling across the
bottom of the screen.
Select Function Bar on the Function List to access the setup
screen. Select the Ticker Tape Setup or the My List Setup for
configuration.
