46 SPEKTRUM NX7e • TRANSMITTER INSTRUCTION MANUAL
EN
The Aircraft Options menu allows you to select a camera gimbal
axis. Select None, 1–Axis, 2–Axis or 3–Axis from the Camera
Options box.
The model icon can be changed by selecting the icon and scrolling
left or right to select.
By default Trims are setup for F Mode, and the trim steps are
defaulted to zero for multirotors. If you want to utilize trim in
multirotor mode, increase the trim step values above zero.
F Mode trim type enables you to save trim values for individual
flight modes if you find, for example, the aircraft requires Roll trim
in Flight Mode 1 but not in Flight Mode 2.
By default switch B is assigned 3 Flight Modes. You can assign up
to five flight modes using any combination of up to two switches.
Channel Assign
Scroll and Select Channel to assign channel inputs and outputs for
each Flight Mode. Each channel can be assigned any switch on the
transmitter including but not limited to trim switches, gimbals and
the Clear/Back buttons.
EXAMPLE: Assign Flight Mode 1 to be your primary flight
mode where your gimbals control primary flight axis. Switching
to Flight Mode 2, you can have the gimbals control the camera
axis and the trim buttons control primary flight axis.
TIP: You can also access the Channel Assign from the Channel
Assign Menu in System Setup.
CAUTION: Always do a Control Test of your model with
the transmitter after programming to make sure your
model responds as desired.
NOTICE: Refer to your multirotor manual for programming
recommendations.
To change the multirotor icon:
In the Aircraft Options screen, roll to select the image. Click once
on the image and roll left or right for optional images.
MULTI (MULTIROTOR)
F-Mode Setup
Aircraft Options
Trim Setup
