SP7-10, SP7-11, SP7-12 and SP7-20, SP7-21, SP7-22 Parameterization
With this parameter you can leave the configuration level. The positioner returns to the operating level. Here you can either save
data in the non-volatile memory or discard all previously made changes (also the changes in other parameter groups).
NV_SAVE Saves settings in the non-volatile memory.
CANCEL Discards all changes made since the last permanent save operation.
3.13.4 ALRM_DO – Digital Output Status
Use this parameter to determine the status of the digital outputs.
'ACTIVE' : Digital output (DO) is active
'INACTIVE' : Digital output (DO) is NOT active
TEST
Test is for simulation of digital outputs (DO, SW1 and SW2).
NOTE
The test is automatically stopped after two minutes and can be aborted by pressing any button.
While the test is running, the corresponding message (see below) will be visible in the display.
NONE No function
ALRM_ON Alarm is simulated (DO active)
SW1_ON Reaching switching point 1 is simulated (SW1 active)
SW2_ON Reaching switching point 2 is simulated (SW2 active)
ALL_ON Alarm and switching points are simulated (all DOs active)
Note: SW1 and SW2 must be fitted as options
