Spirax Sarco SP7-10 - Profibus PA and Foundation Fieldbus Parameter Descriptions (SP7-11, SP7-12 and SP7-21, SP7-22)

IM-S51-07 CTLS Issue 1
54
SP7-10, SP7-11, SP7-12 and SP7-20, SP7-21, SP7-22 Parameterization
3.17 Profibus PA and Foundation Fieldbus parameter descriptions
(SP7-11, SP7-12 and SP7-21, SP7-22)
Parameter Display Function
Possible
parameter setting
Unit
Factory
setting
P2._ SETPOINT
P2.2 CHARACT Charact. curve
Characteristic
curve
LINEAR, 1:25, 1:50,
25:1, 50:1, USERD
--- LINEAR
P2.3 ACTION Valve action Effective direction DIRECT, REVERSE --- DIRECT
P2.4 SHUT_CLS Shut-off value 0% Shut-off value 0 % OFF, 0.1 … 45.0 % 1.0
P2.5 RAMP UP Set point ramp up Setpoint ramp (up) OFF, 0 … 200 --- OFF
P2.6 RAMP DN
Set point ramp
down
Setpoint ramp
(down)
OFF, 0 … 200 --- OFF
P2.7 SHUT_OPN
Shut off value
100%
Shut-off value
100 %
55.0 … 100.0, OFF % OFF
P2.8 EXIT Return
Return to
operating level
Function --- NV_SAVE
P3._ ACTUATOR
P3.0 MIN_RGE
Min. of stroke
range
Operating range,
min.
0.0 … 90.0 % 0.0
P3.1 MAX_RGE
Max. of stroke
range
Operating range,
max.
100.0 … 10.0 % 100
P3.2 ZERO_POS Zero position Zero position
CLOCKWISE,
CTCLOCKWISE
--- CTCLOCKWISE
P3.3 EXIT Return
Return to
operating level
Function --- NV_SAVE
P6._ MAN_ADJ
P6.0 MIN_VR Min. valve range
Operating range,
min.
0.0 … 100.0 % 0
P6.1 MAX_VR Max. valve range
Operating range,
max.
0.0 … 100.0 % 100
P6.2 ACTUATOR Actuator type Actuator type LINEAR, ROTARY --- LINEAR
P6.3 SPRNG_Y2 Spring action (Y2) Spring action (Y2)
CLOCKWISE,
CTCLOCKWISE
--- CTCLOCKWISE
P6.5 EXIT Return
Return to
operating level
Function --- NV_SAVE
