Spirax Sarco SP7-10 - Profibus PA & Foundation Fieldbus Parameters

53
IM-S51-07 CTLS Issue 1
SP7-10, SP7-11, SP7-12 and SP7-20, SP7-21, SP7-22 Parameterization
3.16 Profibus PA and Foundation Fieldbus parameter descriptions (SP7-11, SP7-12
and SP7-21, SP7-22) - PROFIBUS PA and Foundation Fieldbus parameter
overview
Parameter Display Function
Possible
parameter setting
Unit
Factory
setting
P1._ STANDARD
P1.0 ACTUATOR Actuator type Actuator type LINEAR, ROTARY --- LINEAR
P1.1 AUTO_ADJ Auto adjust Autoadjust Function --- ---
P1.2 TOL_BAND
Tolerance band
(zone)
Tolerance band
(zone)
0.3 … 10.0 % 2.0
P1.3 DEADBAND Deadband Dead band 0.10 … 10.00 % 0.20
P1.4 TEST Test Test Function --- INACTIVE
P1.5* ADRESS Profibus Address Set Adress 3...125 --- 3
P1.6 EXIT Return
Return to
operating level
Function --- NV_SAVE
Operating level
Configuration level
Parameter "EXIT"
