PXS-710D Section 1
14
o 7% for equipment which is;
 Attended whilst in use (for example: hair dryers, vacuum cleaners,
kitchen equipment such as mixers, garden equipment such as lawn
mowers, portable tools such as electric drills), or
 Switched on automatically, or is intended to be switched on
manually, no more than twice per day, and also has either a delayed
restart (the delay being not less than a few tens of seconds) or
manual restart, after a power supply interruption
Pst and Plt requirements were not applied to voltage changes caused by manual
switching.
The limits were not applied to voltage changes associated with emergency switching
or emergency interruptions.
Electrostatic Discharge
IEC 61000-4-2
Complies
+/- 8.0 kV, contact
+/- 2 kV, +/- 4 kV, +/- 8 kV, +/- 15 kV, Air
Radiated Immunity
IEC 61000-4-3
Complies
3 V/m 3 V/m
80 to 1000 MHz 1.0 to 2.7 GHz
80 % AM at 1kHz
Electrical Fast
Transient/Burst, Power
Ports,
I/O Ports
IEC 61000-4-4
Complies
Power Ports: +/- 0.5 kV, +/- 1.0 kV, +/- 2.0 kV
IO Ports: +/- 0.25 kV, +/- 0.5 kV, +/- 1.0 kV
100 Hz repetition frequency
Surge Immunity
IEC 61000-4-5
Complies
+/- 0.5 kV, +/- 1.0 kV Differential Mode
+/- 0.5 kV, +/- 1.0 kV, +/- 2.0 kV Common Mode
Conducted Immunity
Power Ports, I/O Ports
IEC 61000-4-6
Complies
Power Ports:
3 Vrms
0.15 to 80 MHz
6 Vrms in ISM test bands: 6.765 to 6.795, 13.553 to 13.567, 26.957 to
27.283, 40.660 to 40.700 MHz
1 kHz, 80%, AM
IO Ports:
3 Vrms
0.15 to 80 MHz
1 kHz, 80%, AM
Magnetic Immunity
IEC 61000-4-8
Complies
30 A/M RMS
50 Hz
Voltage Dips,
Interrupts and
Variations
IEC 61000-4-11
Complies
0 % Ut 0.5 cycle (Variations)
At 0°, 45°, 90°, 135°, 180°, 225°, 270°, and 315°
0 %t, 1 cycle (Variations)
And
70 % Ut, 25 cycles
Single Phase at 0°
0 % Ut, 250 cycles (Interrupts)
