PXS-710D Section 1
13
TABLE 1.1
EMISSIONS & IMMUNITY CHART
Emissions and Immunity Test Standards Compliance
Emissions test Compliance
Immunity Test Level
(Professional Health Care Facility)
RF emissions
CISPR 11
Group 1
Conducted Emissions
Frequency
Range
Group 1, Class A
Limit [dBuV]
Quasi Peak Average
0.15 to 0.50 79.0 66.0
0.50 to 5.00 73.0 60.0
5.00 to 30.0 73.0 60.0
The lower limit applies at all transition frequencies.
Radiated Emissions
Frequency
Range
Group 1, Class A
Quasi-Peak Limit [dBuv/M]
10.0 Meters 3.0 Meters
30 to 230
MHz
40 50
230 MHz to
1 GHz
47 57
RF emissions
CISPR 11
Class A
Harmonic emissions
IEC 61000-3-2
Complies
Harmonic Order
N
Maximum Permissible
Harmonic Current
A
Odd Harmonics
3 2.30
5 1.14
7 0.77
9 0.40
11 0.33
13 0.21
15 ≤ n ≤ 39 0.15 * (15/n)
Even Harmonics
2 1.08
4 0.43
6 0.30
8 ≤ n ≤ 40 0.23 * (8/n)
Voltage
fluctuations/flicker
emissions
IEC 61000-3-3
Complies
The limits shown below were used to determine compliance to the requirements of
IEC 61000-3-3.
The value of Pst shall not be greater than 1.0;
The value of Plt shall not be greater than 0.65;
The value of d(t) during a voltage change shall not exceed 3.3% for more
than 500ms;
The relative steady-state voltage change, dc, shall not exceed 3.3%;
The maximum relative voltage change dmax shall not exceed;
o 4% without additional conditions;
o 6% for equipment which is;
Switched manually, or
Switched automatically more frequently than twice per day, and also
has either a delayed restart (the delay being not less than a few tens
of seconds), or manual restart, after a power supply interruption
