120-10 January, 2016
Model F120 UV/IR Flame Detector
Environmental Specications
Operating Temperature ......... -40°F to 185°F (-40°C to 85°C)
Operating Humidity ............... 0-100% RH, non-condensing
Ingress Protection ................. IP66
Mechanical Specications
Dimensions ........................... 4.40 x 5.25 inches (112 x 133 mm)
Weight ................................... 4.0 lbs (1.8 kg) Aluminum
10.0 lbs (4.5 kg) Stainless Steel
Housing ................................. Aluminum or Stainless Steel
(1) Front Housing
(2) Viton O-Ring Seal
(3) Self-test UV Emitter
(4) Plug-in Electronics Module
(5) Terminal Blocks
(6) Rear Housing
