January, 2016 120-43
Model F120 UV/IR Flame Detector
Tools Required
Safety Systems Technology has specically designed a portable ame detector test lamp to
test its ame detectors.
SST Part # Description
194-1 Model FT194 Flame Detector Test Lamp with rechargeable batteries
and 120 volt battery charger, carrying case included
194-2 Model FT194 Flame Detector Test Lamp with standard “D” cell
batteries, carrying case included
194-3 Model FT194 Flame Detector Test Lamp with rechargeable
batteries and 240 volt battery charger, carrying case included
!
WARNING: The Model FT194 Flame Detector Test Lamp is not rated for use
in hazardous locations. De-classify the area to reduce the risk of ignition of
hazardous atmosphere. DO NOT use the test lamp where combustible and
ammable gases are present.
Step-by-step Test Procedure
!
WARNING: DO NOT look directly into the test lamp while it is on. Never point the
test lamp at another person while it is on. When operating the ame detector test
lamp, shortwave ultraviolet radiation is emitted which can damage your eyesight.
1. To test a ame detector, position the ame detector test lamp within 5 feet (1.5 meters)
from the ame detector and directly within its eld of view.
2. While aiming directly at the detector, PRESS and HOLD the test lamp switch. The
response of the detector will depend on the distance between the detector and the test
lamp.
3. Once the detector has detected the UV and IR radiation from the test lamp, the red
LED will illuminate which can be seen from the viewing window of the detector.
4. Depress the test lamp switch once detector’s red LED is turned on.
For ame detectors with the Delayed Alarm set to NON-LATCHING, the detector will
automatically reset and the red LED will turn off.
For ame detectors with the Delayed Alarm set to LATCHING, the detector will have to
be manually reset to return to normal operation.
This concludes your test and you have conrmed the detector is operating normally.
